Si38-606 List of Electrical and Functional Parts
Appendix 223
Parts Name Symbol
Model
Remark
FXYD20
KAVE
FXYD25
KAVE
FXYD32
KAVE
FXYD40
KAVE
FXYD50
KAVE
FXYD63
KAVE
Remote
Controller
Wired Remote
Controller
BRC1C62 Option
Wireless Remote
Controller
C/O BRC4C64 Option
Motors Fan Motor M1F
AC 220~240V/220V 50/60Hz
1
φ
45W 1
φ
65W
Thermal Protector 135°C
Thermistors
Thermistor (Suction
Air)
R1T
ST8601-2
φ
4 L400
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High
Temp.)
R3T
ST8605-2
φ
8 L400
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602-2
φ
6 L400
20k
Ω
(25°C)
Others
Float Switch 33H FS-0211
Fuse F1U 250V 10A
φ
5.2
Transformer T1R TR22M21R8
