Daikin FXL40LVE [5/6] Cleaning the drain straner

English 2

HOW TO CLEAN AIR OUTLET AND OUTSIDE PAN-

ELS

1. Clean with soft cloth.

2. When it is difficult to remove stains, use water or neutral

detergent.

NOTES

• Do not use gasoline, benzene, thinner, polishing powder,

liquid insecticide. It may cause discoloring or warping.

• Do not let the indoor unit get wet. It may cause an electric

shock or a fire.

• Clean the air inlet grille when it is shut.

• Do not wash the air conditioner with hot water of more than

50°C. Doing so may result in discoloration or deformation.

REMOVAL AND INSTALLATION OF DISCHARGE

GRILL

Refer to figure 3 on page [1]

1. Lift the rear using the front as a fulcrum. To install

use the opposite method.

CLEANING THE DRAIN STRANER

The drain strainer clears dirt in the drain water and prevents

the pipe from clogging. However, if the strainer mesh gets

clogged, water may overflow. Remove and wash the mesh

with water before and after seasons when the unit is in use

and once during those seasons.

1. Remove the drain strainer in the drip-pan under the

drain-pan and wash off any dirt that may have accu-

mulated.

Refer to figure 4 on page [1]

1. Drain-pan

2. Drain straner(take out)

3. Drip-pan

2. Return the drain strainer to its previous position so

that the strainer does not leak water.

• Because cleaning requires removing the front panel,

contact the dealer where you bought the product.
