※AB-Type
tc
: Max. Case Temperature
tc
60W Constant Voltage + Constant Current LED Driver
HLG-60H series
Io Vo
ADJ
ADJ
300 20±
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
9.6
11.9
147.2
171
61.5
46.5
32
ψ×4.2 4PL
300 20±
73.6
30.75
36.8
SJOW 17AWG&H05RN-F 1.0mm *3C
2
-V(Black)
+V(Red)
File Name:HLG-60H-SPEC 2018-09-30
※B-Type
tc
: Max. Case Temperature
tc
300 20±
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
9.6
11.9
147.2
171
61.5
46.5
32
ψ×4.2 4PL
300 20±
73.6
30.75
36.8
-V(Black)
+V(Red)
DIM-(White)
DIM+(Blue)
UL2517 20AWG*2C
SJOW 17AWG&05RN-F 1.0mm *2C
2
SJOW 17AWG&05RN-F 1.0mm *2C
2
SJOW 17AWG&H05RN-F 1.0mm *3C
2
DIM-(White)
DIM+(Blue)
UL2517 20AWG*2C
