Daikin FXLQ40MAVE [4/27] Vrv indoor units

FXLQ-MAVE / FXNQ-MAVE

Model FXLQ32MAVE FXLQ40MAVE

Power supply 1 phase, 220-240/220 V, 50/60 Hz 1 phase, 220-240/220 V, 50/60 Hz

+1 +3 Cooling capacity

kcal/h 3,100 3,900

Btu/h 12,300 15,400

kW 3.6 4.5

+2 +3 Heating capacity

kcal/h 3,400 4,300

Btu/h 13,600 17,100

kW 4.0 5.0

Power input

Cooling

50 Hz kW 0.090 0.090

60 Hz kW 0.079 0.084

Heating

50 Hz kW 0.090 0.090

60 Hz kW 0.079 0.084

Casing / Colour Ivory white (5Y7.5/1) Ivory white (5Y7.5/1)

Dimensions: (H×W×D) mm 600×1,140×222 600×1,140×222

Coil (Cross

¿n coil)

Rows × Stages ×

Fin pitch

mm 3×14×1.5 3×14×1.5

Face area

0.200 0.200

Fan

Model 2D14B13 2D14B13

Type Sirocco fan Sirocco fan

Motor output ×

Number of units

W 25×1 25×1

AirÀow rate (H/L)

m³/min 8/6 11/8.5

l/s 133/100 183/141

cfm 282/212 388/300

Drive Direct drive Direct drive

Temperature control

Microprocessor thermostat for

cooling and heating

Microprocessor thermostat for

cooling and heating

Sound absorbing thermal insulation material Glass ¿ber / Urethane foam Glass ¿ber / Urethane foam

Air ¿lter Resin net (with mould resistance) Resin net (with mould resistance)

Piping

connections

Liquid pipes mm

I6.4 (Flare connection) I6.4 (Flare connection)

Gas pipes mm

I12.7 (Flare connection) I12.7 (Flare connection)

Drain pipe mm

I21 O.D (Vinyl chloride) I21 O.D (Vinyl chloride)

Mass kg 30 30

+4 Sound

pressure level

(H/L)

220 V, 50/60 Hz dB(A) 35/32 38/33

240 V, 50 Hz dB(A) 37/34 40/35

Safety devices Fuse, Thermal protector for fan motor Fuse, Thermal protector for fan motor

Refrigerant control Electronic expansion valve Electronic expansion valve

Standard accessories

Operation manual, Installation manual,

Insulation for ¿tting, Drain hose, Clamps,

Screws, Washers, Level adjustment screw

Operation manual, Installation manual,

Insulation for ¿tting, Drain hose, Clamps,

Screws, Washers, Level adjustment screw

Drawing No.

Speci¿cation C: 3D038816A C: 3D038816A

Sound level C: 4D034564A C: 4D034565A

Notes:

+1. Indoor temp.: 27°CDB, 19°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5 m, level difference: 0 m.

+2. Indoor temp.: 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5 m, level difference: 0 m.

+3. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.

+4. Anechoic chamber conversion value, measured at a point 1.5 m in front of the unit at a height of 1.5 m. During

actual operation, these values are normally somewhat higher as a result of ambient conditions.

Conversion formulae

kcal/h=kW×860

Btu/h=kW×3412

cfm=m³/min×35.3

l/s=m³/min×1000/60

VRV INDOOR UNITS
