Teka EM 60 4G AI AL TR [11/19] Technical information
![Teka EM 60 4G AI AL TR [11/19] Technical information](/views2/1069849/page11/bgb.png)
11
Dimensions and power
Models
Hob dimensions
Height (mm) 90 90 90 90
Length (mm) 600 600 600 600
Width (mm) 510 510 510 510
Dimensions of the positioning in the unit
Length (mm) 560 560 560 560
Width (mm) 480 480 480 480
Depth (mm) 40 40 40 40
Power per burner and hotplate
Rapid gas
burner 3 kW. 1
1
Semi-rapid gas
burner 1.75 kW. 1
1 1 1
Auxiliary gas
burner 1 kW. 1
1 1 1
Triple crown gas
burner 3.8 kW. 1 1 1 1
Electric hotplate
Ø 145 mm, 1
1,500 W
1
Electric:
Nominal Power
(W) for 230V* 0.6 1,500 0.6 1,500
Supply
voltage (V)
SEE THE APPLIANCE’S RATING PLATE
Frequency (Hz) 50 - 60 50 - 60 50 - 60 50 - 60
Gas:
Maximum power kW 9.55 6.55 9.55 6.55
Technical Information
GB
EM/60
4G AI AL TR
(FUND)
EM/60
3G 1P AI AL
TR (FUND)
EM/60
4G AI TR
(FUND)
EM/60
3G 1P AI TR
(FUND)
* For voltages other than 230 V please consult the rating plate
on the appliance.
