ED39-865 Capacity Tables
FXFQ-P (R-410A) 17
1
Refer to Engineering Data concerning about Outdoor Unit Capacity Tables for the actual performance data of each
Indoor and Outdoor Unit combination.
125
-19.8 -20.0 9.4 9.4 9.4 9.4 9.4 9.3
-18.8 -19.0 9.7 9.7 9.7 9.7 9.6 9.6
-16.7 -17.0 10.3 10.3 10.2 10.2 10.2 10.2
-14.7 -15.0 10.9 10.8 10.8 10.8 10.8 10.7
-12.6 -13.0 11.4 11.4 11.4 11.4 11.3 11.3
-10.5 -11.0 12.0 12.0 11.9 11.9 11.9 11.9
-9.5 -10.0 12.3 12.2 12.2 12.2 12.2 12.2
-8.5 -9.1 12.5 12.5 12.5 12.5 12.4 12.4
-7.0 -7.6 13.0 12.9 12.9 12.9 12.9 12.8
-5.0 -5.6 13.5 13.5 13.5 13.4 13.4 13.4
-3.0 -3.7 14.1 14.0 14.0 14.0 14.0 13.9
0.0 -0.7 14.9 14.9 14.8 14.8 14.8 13.9
3.0 2.2 15.7 15.7 15.7 15.5 15.0 13.9
5.0 4.1 16.3 16.2 16.0 15.5 15.0 13.9
7.0 6.0 16.8 16.8
16.0 15.5 15.0 13.9
9.0 7.9 17.3 17.0 16.0 15.5 15.0 13.9
11.0 9.8 17.9 17.0 16.0 15.5 15.0 13.9
13.0 11.8 18.1 17.0 16.0 15.5 15.0 13.9
15.0 13.7 18.1 17.0 16.0 15.5 15.0 13.9
[50 / 60Hz]
Heating Capacity
Unit
Size
Outdoor
air temp.
Indoor air temp.°CDB
16.0 18.0 20.0 21.0 22.0 24.0
°CDB °CWB kW kW kW kW kW kW
