Mechanical Specification
Unit:mm
AC Input Connector (CN1) : JST B6P-VH or equivalent
Pin No.
1
3
6
2,4,5
Assignment
AC/L
AC/N
FG
No Pin
Mating Housing
JST VHR JST SVH-21T-P1.1
or equivalent or equivalent
Terminal
DC Output Connector (CN2) : JST B6P-VH or equivalent
Pin No.
1
2
3,4
5,6
Assignment
DIM+
DIM-
Mating Housing
JST VHR
or equivalent
Terminal
JST SVH-21T-P1.1
or equivalent
3max.
27max.
53
43
T3.15A/300V
FS1
CN2
5
3
4
2
1
6
CN1
5
3
4
2
1
6
3.5
140
147
5
-V
+V
Io
ADJ
SVR1 SVR2
Vo
ADJ
fosc : 100KHz
Block Diagram
Derating Curve Static Characteristics
INPUT VOLTAGE (V) 60Hz
90 100 125 135 145 155 165 175 180 200 230 305
100
90
80
70
60
50
40
LOAD (%)
230VAC
Input only
AMBIENT TEMPERATURE ( )℃
LOAD (%)
-40 -25 0-10 15 30 50 60 70
20
40
50
60
80
100
(HORIZONTAL)
DIM+
DIM-
DETECTION
PWM & PFC
CIRCUIT
O.L.P.O.T.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.L.P.
PFC
CIRCUIT
40W Single Output Switching Power Supply
HLP-40H series
File Name:HLP-40H-SPEC 2014-03-13
: Grounding required
