Mechanical Specification
Unit:mm
fosc : 100KHz
Block Diagram
AC Input Connector (CN1) : JST B6P-VH or equivalent
Pin No.
1
3
6
2,4,5
Assignment
AC/L
AC/N
FG
No Pin
Mating Housing
JST VHR JST SVH-21T-P1.1
or equivalent or equivalent
Terminal
DC Output Connector (CN2) : JST B6P-VH or equivalent
Pin No.
1
2
3,4
5,6
Assignment
DIM+(VR1)
DIM-(VR2)
+V
-V
Mating Housing
JST VHR
or equivalent
Terminal
JST SVH-21T-P1.1
or equivalent
3max.
DIM+
DIM-
DETECTION
PWM & PFC
CIRCUIT
O.L.P.O.T.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.L.P.
PFC
CIRCUIT
HS1
HS2
230VAC
Input only
AMBIENT TEMPERATURE ( )℃
-40 -25 0-10 15 30 50 60 70
20
40
50
60
80
100
(HORIZONTAL)
Derating Curve Static Characteristics
INPUT VOLTAGE (V) 60Hz
90 100 125 135 145 155 165 175 180 200 230 305
100
90
80
70
60
50
40
LOAD (%)
80W Single Output Switching Power Supply
HLP-80H series
File Name:HLP-80H-SPEC 2014-03-13
29.5max.
53
43
4-ψ3.5
T3.15A/300V
/350V
CN2
FS1
SVR1
5
3
4
2
1
6
5
3
4
2
1
6
CN1
SVR2
3.5 159.5
167
5
HS1,HS2 can not be shorted
: Grounding required
