24
FEATURES AND OPTIONS
RGBW WWCW NWDW
RDMDMX RFU
IK09IP67
32.8 KG
BEAM ANGLE REFERENCE
PHOTOMETRIC DETAILS AVAILABLE ON OUR WEBSITE
ACCESSORIES
517 mm
756 mm
150 mm
[20.3”]
[5.9”]
[29.7”]
40°
+90°
+100° -30°
+100° -30°
RAL9003
GRIVEN GREY
RAL7016 RAL9005
CLASS
DIGITAL CONTROL SYSTEM SPECIFICATIONS AND CONFIGURATIONS AVAILABLE ON OUR WEBSITE
TECHNICAL SPECIFICATIONS
CAPITAL 600 US is an IP67 powerful single-mount light tting, whose die cast aluminium body hosts 120 high
brightness RGBW, Dynamic White, Cold White, Natural White, Warm White or, on request, monochrome power
LEDs. Dimensions: 517 mm x 150 mm x 756 mm. Available in DMX, automatic and Master-Slave mode, it also
features RFU (Remote firmware update), and RDM (Remote device management) functions. DALI or DMX-
RDM wireless control available on request. Unless an RDM compatible control is used, one Infrared Remote
Control AL1321 must always be purchased for one or more CAPITAL 600 US units in order to access DMX
addressing, stand-alone operations and DMX channels congurations. Power supply: standard 100÷277V /
50-60Hz. Power consumption: 1.9A @ 230V / 406W max. An Electrical Class I appliance, it also features self-
resetting fuse protection as well as integrated electronic thermal protection management. The Polar Edition,
tted with an integrated de-icing system with electrically heated glass, is available on request. Operating
temperature: -40°C to 50°C (-40°F to 122°F).
AL8235
VISOR (one for each bank)
AL8236
SNOOT (one for each bank)
AL1321 INFRARED
REMOTE CONTROL
AL8237 WIRE GUARD
(one for each bank)
CAPITAL
600 US
MAX OUTPUT
20300 lm
(US CW conguration)
ULTRA SPOT 3.2°
CODES
AL5024 CAPITAL 600 US
AL5025 CAPITAL 600 US POLAR EDITION
LED TYPE
RN RGB+W 4000K
DW From 2700K to 6500K
CW Cold White 6500K
NW Natural White 4000K
WW Warm White 3000K
NOTES
Unless an RDM compatible control is used, CAPITAL 600 US must always be purchased with AL1321 Infrared
Remote Control. More CAPITAL 600 US units can be controlled with one AL1321. *CAPITAL 600 US must always
be purchased with two of the above listed optics.
CABLE TYPE
S POWER IN, DMX IN, DMX OUT
C Monocable with connectors
M Monocable without connectors
OPTICS*
AL8238 ULTRA SPOT OPTICS
CONTROL SYSTEM
R DMX-RDM
W DMX-RDM wireless
D DALI
FINISH
W White RAL 9003
G GRIVEN Grey
A Anthracite RAL 7016
B Black RAL 9005
DALI
ANTI-SALINE
WIRELESS DATA
POLAR
