English 3
Table 2
NOTE
• If the you wishes to use a remote controller that is not listed
above, select a suitable remote controller after consulting
catalogs and technical materials.
FOR THE FOLLOWING ITEMS, TAKE SPECIAL
CARE DURING CONSTRUCTION AND CHECK
AFTER INSTALLATION IS FINISHED.
a. Items to be checked after completion of work
b. Items to be checked at time of delivery
Also review the “SAFETY PRECAUTIONS”
c. Points for explanation about operations
2-4 NOTES TO INSTALLER
Be sure to instruct customers how to properly operate the
unit (especially cleaning filters, operating different functions,
and adjusting the temperature) by having them carry out
operations themselves while looking at the manual.
3. SELECTING INSTALLATION SITE
Please attach additional thermal insulation material to the unit
body when it is believed that the relative humidity in the ceiling
exceeds 80%. Use glass wool, polyethylene foam, or similar
with a thickness of 10 mm or more as thermal insulation mate-
rial.
(1) Select an installation site where the following condi-
tions are fulfilled and that meets with your
customer’s approval.
• Where optimum air distribution can be ensured.
• Where nothing blocks air passage.
• Where condensate can be properly drained.
• In the upper space of the indoor unit where there is no
possible dripping of water from the refrigerant pipe, drain
pipe, water pipe, etc.
• If supporting structural members are not strong enough
to take the unit’s weight, the unit could fall out of place
and cause serious injury.
• Where the false ceiling is not noticeably on an incline.
• Where there is no risk of flammable gas leakage.
• Where sufficient clearance for maintenance and service
can be ensured.
• Where piping between indoor and outdoor units is possi-
ble within the allowable limit. (Refer to the installation
manual for the outdoor unit.)
• Any vents, light fixtures, or other appliances which may
disturb the airflow might cause the top side to become
dirty if located too nearby, so follow the figure below when
installing.
• Install the indoor and outdoor units, power supply wiring
and connecting wires at least 1 meter away from televi-
sions or radios in order to prevent image interference or
noise.
(Depending on the radio waves, a distance of 1 meter
may not be sufficient enough to eliminate the noise.)
Remote controller
Wired type
Wireless type
Heat pump type
Cooling only type
Items to be checked
If not properly done, what is
likely to occur
Check
Are the indoor and outdoor
unit fixed firmly?
The units may drop, vibrate
or make noise.
Is the gas leak test finished?
It may result in insufficient
cooling.
Is the unit fully insulated? Condensate water may drip.
Does drainage flow
smoothly?
Condensate water may drip.
Does the power supply volt-
age correspond to that
shown on the name plate?
The unit may malfunction or
the components burn out.
Are wiring and piping cor-
rect?
The unit may malfunction or
the components burn out.
Is the unit safely grounded?
Dangerous at electric leak-
age.
Is wiring size according to
specifications?
The unit may malfunction or
the components burn out.
Is something blocking the air
outlet or inlet of either the
indoor or outdoor units?
It may result in insufficient
cooling.
Are refrigerant piping length
and additional refrigerant
charge noted down?
The refrigerant charge in the
system is not clear.
Items to be checked Check
Did you explain about operations while showing the
instruction manual to your customer?
Did you hand the instruction manual over to your cus-
tomer?
The items with WARNING and CAUTION marks
in the instruction manual are the items pertaining to
possibilities for bodily injury and material damage in
addition to the general usage of the product. Accordingly, it
is necessary that you make a full explanation about the
described contents and also ask your customers to read the
instruction manual.
≥350
≥1500≥1500
≥1000
[ Space required for installation ]
≥100 ≥100
(length:mm)
2500 or more
For installation
in high places
