GOBOSTORM & GOBOSTORM PLUS MK2 | outdoor use
TECHNICAL SPECIFICATIONS
GOBOSTORM
MSD 575W metal halide lamp
Lamp life: 3000 hours
MSR 575W metal halide lamp
Lamp life: 1000 hours
Manual adjustment of focus and beam angle
(10° or 20°)
One rotating gobo slot hosts either metal or
glass gobos (ø ext. 53.3 - ø int. 40 mm)
One dichroic filter can also be used in
combination with a metal gobo
DMX, automatic and Master-Slave mode
Power supply:
200÷220V / 230÷250V / 50-60Hz
Power consumption:
4.3A @ 230V 730W max
Electrical class: I
Meets CE safety standards
Pressure die cast aluminium body
with an adjustable mounting yoke
IP65
Unit: 20 Kg - Ballast: 12 Kg
GOBOSTORM PLUS MK2
MSD 575W metal halide lamp
Lamp life: 3000 hours
MSR 575W metal halide lamp
Lamp life: 1000 hours
Manual adjustment of focus and
beam angle (10° or 20°)
One rotating gobo wheel hosts either 5 metal
or glass indexable gobos (ø ext. 53.3 - ø
int. 40 mm)
Effects wheel: 3-facet prism, 5-facet prism,
3-D prism, 1 frost filter
1 rotating wheel for 8 different colours +
white (including UV filter)
Variable speed blackout effect
Linear 0-100% dimmer function
9 fps strobe maximum speed
DMX (also wireless on request), automatic
and Master-Slave mode
Remote firmware update (RFU)
RDM function
Test mode for trouble shooting operation
Power supply:
200÷220V / 230÷250V / 50-60Hz
Power consumption:
3.9A @ 230V 635W max
Electrical class: I
Meets CE safety standards
Pressure die cast aluminium body
with an adjustable mounting yoke
IP65
Unit: 25 Kg
Ballast: 12 Kg
SPECIFICHE TECNICHE
GOBOSTORM
Lampada a ioduri metallici MSD 575W
Durata: 3000 ore
Lampada a ioduri metallici MSR 575W
Durata: 1000 ore
Regolazione manuale della messa a fuoco
e dell’angolo di proiezione (10° o 20°)
Alloggiamento per un gobo rotante
in
metallo o in vetro
(ø est. 53,3 - ø int. 40 mm)
In combinazione con un gobo metallico
si può utilizzare un filtro dicroico
Funzionamento in automatico, modalità
Master-Slave e controllo remoto DMX
Alimentazione:
200÷220V / 230÷250V / 50-60Hz
Consumo:
4.3A @ 230V 730W max
Classe elettrica: I
Rispetta le norme CE
Corpo in alluminio pressofuso con staffa
di montaggio regolabile
IP65
Proiettore: 20 Kg - Ballast: 12 Kg
GOBOSTORM PLUS MK2
Lampada a ioduri metallici MSD 575W
Durata: 3000 ore
Lampada a ioduri metallici MSR 575W
Durata: 1000 ore
Regolazione manuale della messa a fuoco e
dell’angolo di proiezione (10° o 20°)
Ruota per 5 gobo indicizzabili in metallo
o in vetro (ø est. 53,3 - ø int. 40 mm)
Effetti speciali: prisma a 3 facce, prisma a 5
facce, prisma 3D, 1 filtro frost
1 ruota colori per 8 diversi colori + bianco
(con filtro UV)
Effetto blackout a velocità variabile
Funzione dimmer lineare 0-100%
Effetto strobo a velocità max 9 fps
Funzionamento in automatico, modalità
Master-Slave e controllo remoto DMX
(anche wireless su richiesta)
Aggiornamento firmware da remoto (RFU)
Funzione RDM
Modalità test
Alimentazione:
200÷220V / 230÷250V / 50-60Hz
Consumo: 3,9A @ 230V 635W max
Classe elettrica: I
Rispetta le norme CE
Corpo in alluminio pressofuso con staffa
di montaggio regolabile
IP65
Proiettore: 25 Kg
Ballast: 12 Kg
GR0466 GOBOSTORM
GR0660 GOBOSTORM PLUS MK2
ACCESSORIES / ACCESSORI CODES / CODICI
AD4118
POWER CDI COMMANDER
AD4119
POWER CDI COMMANDER PLUS
GR0470 FIXING PLATE
GR0590 OPTIONAL OPTICS (21°÷38°)
LP0997 MSD 575W LAMP
506
645
605
213 368
176
Description :
Revision :
Scale :
Code :
Weight :
Note :
http://www.griven.com
Copyright
©
2011 , GRIVEN S.r.l. World Lighting Challenge
GOBOSTORM
GR0466
1:1
SHEET 1 OF 1
A-02
506
645
605
213 368
176
Description :
Revision :
Scale :
Code :
Weight :
Note :
http://www.griven.com
Copyright
©
2011 , GRIVEN S.r.l. World Lighting Challenge
GOBOSTORM
GR0466
1:1
SHEET 1 OF 1
A-02
506 645
605
213
368
176
Description :
Revision :
Scale :
Code :
Weight :
Note :
http://www.griven.com
Copyright
©
2011 , GRIVEN S.r.l. World Lighting Challenge
GOBOSTORM
GR0466
1:1
SHEET 1 OF 1
A-02
506 645
605
213
368
176
Description :
Revision :
Scale :
Code :
Weight :
Note :
http://www.griven.com
Copyright
©
2011 , GRIVEN S.r.l. World Lighting Challenge
GOBOSTORM
GR0466
1:1
SHEET 1 OF 1
A-02
PHOTOMETRIC DETAILS
AVAILABLE ON OUR WEBSITE
DATI FOTOMETRICI DISPONIBILI
SUL NOSTRO SITO
AD4125
POWER CDI COMM. PLUS IP20
GR0661 PERFLUOROPOLYETHER
UNIFLOR
AL3362 IP20 WIRELESS DMX TRANSMITTER
AL3364 IP65 WIRELESS DMX TRANSMITTER
AL3366 IP65 WIRELESS DMX REPEATER
AL3360 IP65 WIRELESS
DMX RECEIVER
PROJECTION ANGLE
GOBOSTORM 10°- 20°
GOBOSTORM PLUS MK2 10°- 20°
AL1424 WALL-TSC
AL2660 WEEZERD 1
506
598
660
213 368
174
Description :
Revision :
Scale :
Code :
Weight :
Note :
http://www.griven.com
Copyright
©
2014 , GRIVEN S.r.l. World Lighting Challenge
GOBOSTORM PLUS MK2
GR0660
1:1
SHEET 1 OF 1
A-01
506
598
660
213 368
174
Description :
Revision :
Scale :
Code :
Weight :
Note :
http://www.griven.com
Copyright
©
2014 , GRIVEN S.r.l. World Lighting Challenge
GOBOSTORM PLUS MK2
GR0660
1:1
SHEET 1 OF 1
A-01
GOBOSTORM
GOBOSTORM PLUS MK2
IP65 /
