MEAN WELL LCM-60 [4/5] Lcm 60

60%

1V0V 4V 7V2V 5V 8V3V 6V 9V 10V

10%0% 20% 30% 40% 50% 70% 80%

OPEN

90% 100%~108%

100%~108%

100 %

Di mmin g va lue

Output current

※ 0 ~ 10V dimming function for outp ut cur rent adjustment (Typical)

60%

20%

30%

40%

50%

70%

80%

90%

100%

100%Du ty value

Output current

※ Bu ilt-in 2 in 1 dimming function, outpu t constant cur rent level can be adjusted through output te rminal by 0 ~ 10Vdc or 10V PWM sig nal

betwee n DIM+ and DIM-.

※ Plea se DO NOT connect "D IM- " to "-Vo".

※ 10V PWM signal for outpu t current adju stment (Typical): Frequ ency range :100H z ~ 3KHz

‧10 drivers(max.) synchronization (1 master + 9 slaves)

‧Maximum cable length between each units : 20 meter.

DIMMING OPERATION

SYNCHRONIZATION OPERATION

LCM-60

(Slave 2)

- - -- - -

SYN.

LCM-60

(Master)

LCM-60

(Slave 1 )

10%

20m 20m

File Name :LCM-60 -SPEC 2014-01-0 7

60W Multiple-Stage Output Current LED Power Supply

LC M -60

s eries
