MEAN WELL LDC-35 [3/9] Series
![MEAN WELL LDC-35 [3/9] Series](/views2/1701435/page3/bg3.png)
BLOCK DIAGRAM
PFC fosc : 50~400KHz
PWM fosc : 30~200KHz
DETECTION
PWM & PFC
CIRCUIT
O.L.P.O.T.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
CONTROL
O.V.P.
&
CP.
CASE GROUND
DIM+
(B Type)
DIM-
File Name:LDC-35-SPEC 2018-02-02
LDC-35 series
35W Constant Power MODE Linear LED Driver
VOLTAGE
LDC-35
LDC-35
CURRENT
0V
10V
20V
30V
40V
50V
60V
100mA 300mA 500mA 700mA 900mA 1100mA
1A 0.9A 0.8A 0.7A
0.62A
0.6A
0.45A
0.4A 0.35A
Note: output power 35W≤
Vo-
Vo-
Vo+
Vo+
NTC
DIM+
NTC
IADJ
IADJ
resistor
DIM-
TB2
15.2K
24.5K 43K 100K 300K
0.3A
NC150K
19K
32.5K 46K
0.5A
72.5K
56V
27V
◎I-V Operating Area.
Output rated current level can be adjusted by a additive resistance.
◎ Rated current setting table
OUTPUT CURRENT SETTING
