MEAN WELL LDC-80B [2/9] Series

SPECIFICATION

MODEL

OUTPUT

SET UP TIME

Note.4

VOLTAGE RANGE Note.3

FREQUENCY RANGE

POWER FACTOR

(Typ.)

EFFICIENCY (Typ.)

AC CURRENT(Typ.)

INPUT

INRUSH CURRENT

(Typ.)

LEAKAGE CURRENT

SAFETY STANDARDS

Note.5

EMC IMMUNITY

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSION

OTHERS

NOTE

PACKING

OVER TEMPERATURE

500ms/230VAC

(Please refer to "STATIC CHARACTERISTIC" section)

47 ~ 63Hz

PF 0.95/230VAC@load 50%; PF 0.92/277VAC@load 75%≧≧≧≧

(Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)

0.48A / 230VAC 0.36A/277VAC

<0.75mA / 277VAC

Compliance to

EN55015,EN61000-3-2 Class C (@load 50%) ; EN61000-3-3;GB/T17743,GB17625.1≧

20 ~ 95% RH non-condensing

-40 ~ +80 , 10 ~ 95% RH℃

±℃ ℃0.03%/ (0 ~ 60 )

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

360 30**21mm (L*W*H)

ENVIRONMENT

EMC EMISSION

Note.5

SAFETY &

EMC

PROTECTION

SHORT CIRCUIT

90%(230VAC@Full load)

Hiccup mode or constant current limiting ,recovers automatically after fault condition is removed

I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

File Name:LDC-80-SPEC 2018-02-02

CURRENT TOLERANCE

±5.0%

THD< 10%(@load 50%/230VAC; @load 75%/277VAC)≧≧

(Please refer to “TOTAL HARMONIC DISTORTION(THD)” section)

TOTAL HARMONIC DISTORTION

OPEN CIRCUIT VOLTAGE

(max.)

COLD START 55A(twidth= s measured at 50% Ipeak)/230VAC300 Per NEMA 410μ;

MAX. No. of PSUs on 16A

CIRCUIT BREAKER

6 units (circuit breaker of type B) / 11 units (circuit breaker of type C) at 230VAC

Tcase=-25 ~ +85 (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)℃

MAX. CASE TEMP.

Tcase=+85℃

Compliance to EN61000-4-2,3,4,5,6,8,11; EN61547, light industry level(surge immunity:Line-Earth:2KV,Line-Line:1KV) criteria A

UL8750 ENEC EN61347-1, EN61347-2-13, EN62384; GB19510.14,GB19510.1 approved, CSA C22.2 No. 250.13-12;

1. All parameters NOT specially mentioned are measured at 230VAC input, rated and 25 of ambient temperature.current ℃

2. Please refer to " ".OUTPUT CURRENT SETTING

3. De rating may be needed under low input voltages. Please .- refer to STATIC CHARACTERISTIC sections for details

4. Length of set up time is measured at first cold start. Turning ON/OFF the power supply may lead to increase of the set up time.

5. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the

complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.

6. This series meets the typical life expectancy of >50000 hours of operation when Tcase, particularly point (or TMP, per DLC), is about 75 or less.℃tc

7. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com

8. The ambient temperature derating of 3.5 /1000m with fanless models and of 5 /1000m with fan models for operating altitude higher than 2000m(6500ft).℃℃

0.295Kg; 40pcs/12.8Kg/0.81CUFT

3.0% max. @rated current

180 ~ 295VAC 254 ~ 420VDC

LDC-80 series

LDC-80

60V

80W Constant Power MODE Linear LED Driver

Compliance to IEC62386-101.102.207 for DA-Type only

DALI STANDARDS

DIMMING

FUNCTION

By external NTC, please refer to TEMPERATURE COMPENSATION OPERATION section“”

Please refer to DIMMING OPERATION”section“

CURRENT RIPPLE

Shut down o/p voltage, with auto-recovery

1065K hrs min. Telcordia SR-332 (Bellcore) 259Khrs min. MIL-HDBK-217F (25 )℃

OVER VOLTAGE

Shut down o/p voltage with auto-recovery or re-power on to recovery

61 ~ 80V

TEMP. COMPENSATION

LOW FREQUENCY

OUTPUT CURRENT REGION

RATED POWER Note.2

CONSTANT CURRENT REGION

Note.2

27 ~ 56V

700 ~ 2100mA(700mA default)

80W

FULL POWER CURRENT RANGE

1400 ~ 2100mA
