MAX. No. of PSUs on 16A
CIRCUIT BREAKER
3 units (circuit breaker of type B) / 6 units (circuit breaker of type C) at 230VAC
SPECIFICATION
MODEL LPC-60-1050 LPC-60-1400 LPC-60-1750
DC VOLTAGE RANGE
RATED POWER
OUTPUT
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
Note.6
HOLD UP TIME (Typ.)
VOLTAGE RANGE
Note.4
FREQUENCY RANGE
EFFICIENCY (Typ.)
AC CURRENT (Typ.)
INPUT
INRUSH CURRENT(Typ.)
LEAKAGE CURRENT
SAFETY STANDARDS
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
MTBF
DIMENSIONOTHERS
NOTE
PACKING
OVER VOLTAGE
9 ~ 48V 9 ~ 42V 9 ~ 34V
50.4W 58.8W 59.5W
200mVp-p 200mVp-p 200mVp-p
±5.0%
±1.0%
±2.0%
500ms, 120ms / 230VAC 500ms, 120ms / 115VAC at full load
90 ~ 264VAC 127 ~ 370VDC
47 ~ 63Hz
87%
50.4 ~ 60V 44.1 ~ 56.7V
85%
39.1 ~ 45.9V
87%
1.2A/115VAC 0.7A/230VAC
COLD START 60A(twidth=540 s measured at 50% Ipeak) at 230VACμ
0.25mA / 240VAC
Compliance to EN55032 (CISPR32) Class B, EN61000-3-2 Class A, EN61000-3-3
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, criteria A
-30 ~ +70 (Refer to "Derating Curve")℃
20 ~ 90% RH non-condensing
-40 ~ +80 , 10 ~ 95% RH℃
±℃ ℃0.03%/ (0 ~ 50 )
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
732Khrs min. MIL-HDBK-217F (25 )℃
162.5*42.5*32mm (L*W*H)
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Derating may be needed under low input voltage. Please check the static characteristics for more details.
5. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the
complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.
6. Length of set up time is measured at first cold start. Turning ON/OFF the power supply may lead to increase of the set up time.
7. The unit might not be suitable for lighting applications in EU countries. Please check with your local authorities for the possible use of the unit.
8. Suitable for indoor use or outdoor use without direct sunlight exposure. Please avoid immerse in the water over 30 minute.
0.4Kg; 32pcs/13.8Kg/0.56CUFT
Protection type : Shut off o/p voltage, clamping by TVS diode
60W Single Output Switching Power Supply
Constant current design
Universal AC input / Full range
Withstand 300VAC surge input for 5 seconds
Protections: Short circuit / Over voltage
Cooling by free air convection
Fully encapsulated with IP67 level (Note.8)
Fully isolated plastic case
ⅡClass power unit, no FG
Class 2 power unit
ass LPSP
Suitable for LED related fixture or appliance
(such as LED Decoration or Advertisement devices)(Note.7)
100% full load burn-in test
Low cost, high reliability
2 years warranty
■
Features :
LPC-60 series
RIPPLE & NOISE (max.) Note.2
VOLTAGE TOLERANCE Note.3
ENVIRONMENT
SAFETY &
EMC
PROTECTION
50ms/230VAC 16ms/115VAC at full load
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
I/P-O/P:3KVAC
I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH℃
File Name:LPC-60-SPEC 2017-11-03
RATED CURRENT 1050mA 1400mA 1750mA
±5.0%CURRENT ACCURACY
EMC IMMUNITY
EMC EMISSION
UL1310, CAN/CSA C22.2 No. 223-M91(for LPC-60-1750 only), design refer to TUV EN60950-1IP67, IEC60950-1:2005+A2:2013 approved ;
IP67
LPS
( except for 1750mA )
( for 1750mA only)
