MEAN WELL LPF-40-48 [2/6] Lpf 40

LPF-40 series

SPECIFICATION

MODEL

OUTPUT

VOLTAGE RANGE Note.5

FREQUENCY RANGE

POWER FACTOR

EFFICIENCY (Typ.)

AC CURRENT

INPUT

INRUSH CURRENT(Typ.)

LEAKAGE CURRENT

EMC IMMUNITY

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVER TEMPERATURE

OVER VOLTAGE

47 ~ 63Hz

<0.75mA / 240VAC

Compliance to

EN55015

,EN61000-3-2 Class C (@load≧60%) ; EN61000-3-3

20 ~ 95% RH non-condensing

-40 ~ +80℃, 10 ~ 95% RH

±0.03%/℃ (0 ~ 50℃)

10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

438.8Khrs min. MIL-HDBK-217F (25℃)

ENVIRONMENT

EMC EMISSION Note.8

SAFETY &

EMC

PROTECTION

SHORT CIRCUIT

I/P-O/P:3.75KVAC

I/P-O/P:100M Ohms / 500VDC / 25℃/ 70% RH

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

TOTAL HARMONIC DISTORTION

DC VOLTAGE

RATED CURRENT

RATED POWER Note.5

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME Note.6

HOLD UP TIME (Typ.)

RIPPLE & NOISE (max.) Note.3

VOLTAGE TOLERANCE Note.4

CONSTANT CURRENT REGION Note.2

OVER CURRENT

SAFETY STANDARDS Note.8

COLD START 50A(twidth=210 s measured at 50% Ipeak) at 230VACμ ; Per NEMA 410

MAX. No. of PSUs on 16A

CIRCUIT BREAKER

12 units (circuit breaker of type B) / 20 units (circuit breaker of type C) at 230VAC

MAX. CASE TEMP.

Tcase=+80℃

Compliance to EN61000-4-2,3,4,5,6,8,11; EN61547, light industry level (surge immunity Line-Line 2KV)

(Please refer to "STATIC CHARACTERISTIC" section)

90 ~ 305VAC 127 ~ 431VDC

1.AllparametersNOTspeciallymentionedaremeasuredat230VACinput,ratedcurrentand25℃ofambienttemperature.

2.Pleasereferto"DRIVINGMETHODSOFLEDMODULE".

3.Ripple&noisearemeasuredat20MHzofbandwidthbyusinga12"twistedpair-wireterminatedwitha0.1uf&47ufparallelcapacitor.

4.Tolerance:includessetuptolerance,lineregulationandloadregulation.

5.De-ratingmaybeneededunderlowinputvoltages.Pleasereferto“STATICCHARACTERISTIC”sectionsfordetails.

6.Lengthofsetuptimeismeasuredatfirstcoldstart.TurningON/OFFthedrivermayleadtoincreaseofthesetuptime.

7.Thedriverisconsideredasacomponentthatwillbeoperatedincombinationwithfinalequipment.SinceEMCperformancewillbeaffectedbythe

completeinstallation,thefinalequipmentmanufacturersmustre-qualifyEMCDirectiveonthecompleteinstallationagain.

8.ThemodelcertifiedforCCC(GB19510.14,GB19510.1,GB17743andGB17625.1)isanoptionalmodel.PleasecontactMEANWELLfordetails.

9.To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED driver can only be used behind a switch

without permanently connected to the mains.

10.Thisseriesmeetsthetypicallifeexpectancyof>50,000hoursofoperationwhenTcase,particularlytcpoint(orTMP,perDLC),isabout75℃orless.

11.PleaserefertothewarrantystatementonMEANWELL'swebsiteathttp://www.meanwell.com

40W Constant Voltage + Constant Current LED Driver

95 ~ 108%

Hiccup mode, recovers automatically after fault condition is removed

Constant current limiting, recovers automatically after fault condition is removed

PF≧0.97/115VAC, PF≧0.95/230VAC, PF≧0.92/277VAC@full load

(Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)

THD< 20%(@load≧60%/115VC,230VAC; @load≧75%/277VAC)

(Please refer to “TOTAL HARMONIC DISTORTION(THD)” section)

Tcase=-40 ~ +80℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)

Shut down and latch off o/p voltage, re-power on to recover

12V

LPF-40-12

LPF-40-15

LPF-40-20

LPF-40-24

LPF-40-30

LPF-40-36

LPF-40-42

LPF-40-48

LPF-40-54

7.2 ~12V

15V

9 ~ 15V

20V

12 ~ 20V

24V

14.4 ~ 24V

30V

18 ~ 30V

36V

21.6 ~ 36V

48V

28.8 ~ 48V

3.34A 2.67A 2A 1.67A

1.34A

1.12A

0.84A

40.08W 40.08W 40W 40.08W 40.2W

40.32W

150mVp-p 150mVp-p 150mVp-p 150mVp-p 200mVp-p

250mVp-p

±4.0% ±4.0% ±4.0% ±4.0% ±4.0%

±4.0%

±0.5% ±0.5% ±0.5% ±0.5% ±0.5%

±0.5%

±2.0% ±1.5% ±1.0% ±0.5% ±0.5%

±0.5%

54V

32.4 ~ 54V

0.76A

41.04W

350mVp-p

±4.0%

±0.5%

42V

25.2 ~ 42V

0.96A

40.32W

250mVp-p

±4.0%

±0.5%

1000ms, 80ms / 115VAC 500ms, 80ms / 230VAC

16ms/230VAC 16ms/115VAC

84%

85%

86%

87%

88%

90%88.5% 90%

0.6A / 115VAC 0.3A / 230VAC 0.25A/277VAC

15 ~ 17V 17.5 ~ 21V

23 ~ 27V

28 ~ 35V

34 ~ 40V

41 ~ 49V 54 ~ 63V

46 ~ 54V 59 ~ 66V

Shut down o/p voltage, re-power on to recover

UL8750, CSA C22.2 No. 250.0-08(except for 48V, 54V), ENEC EN61347-1, EN61347-2-13 independent, EN62384, IP67,

J61347-1, J61347-2-13 approved ; design refer to UL60950-1, TUV EN60950-1

162.5*43*32mm (L*W*H)

0.44Kg; 32pcs/15.08Kg/0.93CUFT

File Name:LPF-40-SPEC 2017-04-13
