■ ModelEncoding

■ Description

■ Features ■ Applications

LPF-40D series

‧LEDpanellighting

‧LEDdownlight

‧LEDdecorativelighting

‧LEDtunnellighting

‧Movingsign

LPF-40Dseriesisa40WAC/DCLEDdriverfeaturingtheconstantcurrentoutput.LPF-40D

operatesfrom90～305VACandoffersmodelswithdifferentratedvoltagerangingbetween

12Vand54V.Thankstotheefficiencyupto89%,withthefanlessdesign,theentireseries

isabletooperatefor-40℃~+80℃casetemperatureunderfreeairconvection.Theentireseries

isratedwithIP67ingressprotectionlevelandissuitabletoworkforavarietyofapplicationsat

dry,damporwetlocations.LPF-40Disequippedwiththe3in1dimmingfunctionsoastoprovide

- 48LPF - 40D

Ratedoutputvoltage(12V/15V/20V/24V/30V/36V/42V/48V/54V)

Ratedwattage

Seriesname

‧ConstantCurrentmodeoutput

‧PlastichousingwithClassIIdesign

‧Built-inactivePFCfunction

‧Class2powerunit

‧IP67ratingforindoororoutdoorinstallations

‧Function:3in1dimming

‧Typicallifetime>50000hours

‧5yearswarranty

IP67

F M M

110

SELV

(for48V,54Vonly)

(exceptfor48V,54V)

40W Constant Current Mode LED Driver

thedesignflexibilityforLEDlightingsystem.

File Name:LPF-40D-SPEC 2017-04-13
