(60W)
LPF-60 series
PF
LOAD
OUTPUT LOAD vs TEMPERATURE
STATIC CHARACTERISTIC
TOTAL HARMONIC DISTORTION (THD)
AMBIENT TEMPERATURE,Ta (℃)
LOAD (%)
INPUT VOLTAGE (V) 60Hz
LOAD (%)
(HORIZONTAL)
POWER FACTOR (PF) CHARACTERISTIC
※De-rating is needed under low input voltage.
EFFICIENCY vs LOAD
LPF-60 series possess superior working efficiency that up to 90% can
be reached in field applications.
※ 48V Model, Tcase at 70℃
※ 48V Model, Tcase at 70℃
EFFICIENCY(%)
LOAD
THD
LOAD
※ Tcase at 70℃
60W Constant Voltage + Constant Current LED Driver
Constant Current Mode
LOAD (%)
(HORIZONTAL)
Tcase (℃)
20
40
50
60
80
100
-30 0 15 300 40 50-40 60 70
230VAC
Input only
90 100 125 135 145 155 165 175 180 200 230 305
100
90
80
70
60
50
40
20
40
50
60
80
100
-30 0 15 300 50 60-40 70 80
230VAC
Input only
File Name:LPF-60-SPEC 2017-04-14
