■ ModelEncoding

■ Description

■ Features ■ Applications

File Name:LPF-60D-SPEC 2017-04-14

LPF-60D series

‧LEDpanellighting

‧LEDdownlight

‧LEDdecorativelighting

‧LEDtunnellighting

‧Movingsign

LPF-60Dseriesisa60WAC/DCLEDdriverfeaturingtheconstantcurrentoutput.LPF-60D

operatesfrom90～305VACandoffersmodelswithdifferentratedvoltagerangingbetween

12Vand54V.Thankstothehighefficiencyupto90%,withthefanlessdesign,theentire

seriesisabletooperatefor-40℃~+80℃casetemperatureunderfreeairconvection.Theentire

seriesisratedwithIP67ingressprotectionlevelandissuitabletoworkforavarietyofapplications

atdry,damporwetlocations.LPF-60Disequippedwiththe3in1dimmingfunctionsoastoprovide

- 30LPF - 60D

Ratedoutputvoltage(12V/15V/20V/24V/30V/36V/42V/48V/54V)

Ratedwattage

Seriesname

‧ConstantCurrentmodeoutput

‧PlastichousingwithClassIIdesign

‧Built-inactivePFCfunction

‧Class2powerunit

‧IP67ratingforindoororoutdoorinstallations

‧Function:3in1dimming

‧Typicallifetime>50000hours

‧5yearswarranty

IP67

F M M

110

SELV

(for48V,54Vonly)

(exceptfor48V,54V)

60W Constant Current Mode LED Driver

thedesignflexibilityforLEDlightingsystem.
