■ ModelEncoding

■ Description

■ Features ■ Applications

File Name:LPF-90-SPEC 2017-04-14

90W Constant Voltage + Constant Current LED Driver

LPF-90 series

‧LEDpanellighting

‧LEDdownlight

‧LEDdecorativelighting

‧LEDtunnellighting

‧Movingsign

‧Type“HL”foruseinClassI,Division2

 (Classified)location.hazardous

LPF-90seriesisa90WAC/DCLEDdriverfeaturingthedualmodesconstantvoltageand

constantcurrentoutput.LPF-90operatesfrom90～305VACandoffersmodelswithdifferent

ratedvoltagerangingbetween15Vand54V.Thankstothehignefficiencyupto91%,with

thefanlessdesign,theentireseriesisabletooperatefor-40℃~+70℃casetemperatureunder

freeairconvection.TheentireseriesisratedwithIP67ingressprotectionlevelandissuitable

toworkforavarietyofapplicationsatdry,damporwetlocations.

- 24LPF - 90

Ratedoutputvoltage(15V/20V/24V/30V/36V/42V/48V/54V)

Ratedwattage

Seriesname

‧ConstantVoltage+ConstantCurrentmodeoutput

‧PlastichousingwithClassIIdesign

‧Built-inactivePFCfunction

‧Class2powerunit

‧FullyencapsulatedwithIP67level

‧Typicallifetime>50000hours

‧5yearswarranty

IP67

F M M

110

SELV

(for48V,54Vonly)

(exceptfor48V,54V)

TypeHLTypeHL
