■ Features ■ Applications



Suitable for LED related

fixture or appliance

(such as LED Decoration

or Advertisement devices)

■ Model Encoding

■ Description

LPV-150 and LPVL-150 are 150W single output power supplies that specifically and perfectly work for

LED lighting and LED moving sign applications. As a class II power unit, these two series are housed

with the UL 94V-0 rated flame retardant plastic enclosure. The IP67 design allows every model to fit

the use at dry, damp and wet locations. Both series are constant voltage mode design that various

models with 12V, 15V, 24V, 36V and 48V are offered for LPV-150 where as 12V and 24V are

provided for LPVL-150.

Output voltage

Output wattage

Series name

-12LPV L - 150

Blank: AC input range 180~305VAC

{

L:AC input range 90~132VAC

File Name:LPV-150-SPEC 2017-11-03

150W Single Output Switching Power Supply

LPV-150 series

IP67

Constant voltage design

90~132VAC input for LPVL-150

180~305VAC input for LPV-150

Fully encapsulated with IP67 level (Note.8)

Class power unit, no FGⅡ

Protections: Short circuit/Overload/Over voltage/

Over temperature

Fully isolated plastic case

Fanless design, cooling by free air convection

100% full load burn-in test

Low cost, high reliability

Listed in UL Sign Component Manual (SAM)

Type HL for use in class I, Division 2 hazardous (Classified)

location luminaires for LPVL-150

2 years warranty

(for Blank type only)

(for L type only)
