Plock 1 User Manual Page | 3

Installation step:

1. Pull up the parking lock arm, unlock and remove the top cover.

2. Determine the parking lock installation position, and place the parking lock on the position.

3. Use pen to mark the three holes to confirm drilling positions.

4. According to the position of the three mounting holes, with the model M12 drill bit, drill three

diameter 12mm, 80mm deep hole, and knock the expansion bolt M8 into the hole, and then remove

the nuts.

5. Thread the three holes through the expansion bolt and tighten the nuts.

6. Connect the battery plug and lock the top cover.

7. Start operating the parking lock. If the parking lock operate normally, that is, the installation is

completed.

6. Battery cautions

1. The factory default is not equipped with batteries. Please use alkaline dry batteries (D x 4).

2. Do not heat, disassemble the battery.

3. Do not reverse the battery polarity.

4. Do not put the battery into fire or try to open it.

7. Use cautions

1. When the remote controller is lack of power, the same type of batteries should be replaced in time.

2. Regularly clean the surface of the dust and garbage, try to ensure that the parking lock clean and

dry.
