Mechanical SpecificationMechanical Specification
※ T case: Max. Case Temperature.
H07RN-F 1.5mm 2C
2
×
37.5
1500 20±
Optional Schuko EU plug with IP44
300 20±
H05RN-F 1.0mm 2C
2
×
63
2- 4.5ψ
191
5
5
5
5
95.5
31.5
Plug Assignment
PIN NO.
1,2
,34
All models : Jingcheng GCA012-4P, or
equivalentNeutrik NC4MX, or
OUTPUT
+V
-V
4
4
3
3
2
2
1
1
Installation Manual
Please refer to : http://www.meanwell.com/webnet/search/InstallationSearch.html
Recommend Mounting Direction
500 10±
50 3±
120W Single Output Moistureproof Switching Adaptor
OWA-120E series
File Name:OWA-120E-SPEC 2014-12-30
Case No. PWM-120 Unit:mm
