Daikin FXDQ15A3VEB [5/37] Specifications
![Daikin FXDQ15A3VEB [5/37] Specifications](/views2/1704001/page5/bg5.png)
3
2
• VRV Systems • FXDQ-A3
3
• Indoor Unit • FXDQ-A3
2 Specifications
2-1 Technical Specifications FXDQ15A3 FXDQ20A3 FXDQ25A3 FXDQ32A3 FXDQ40A3 FXDQ50A3 FXDQ63A3
Power input - 50Hz Cooling Nom. kW 0.071 0.078 0.099 0.110
Heating Nom. kW 0.068 0.075 0.096 0.107
Power input - 60Hz Cooling Nom. kW 0.071 0.078 0.099 0.110
Heating Nom. kW 0.068 0.075 0.096 0.107
Required ceiling void \> mm 240
Dimensions Unit Height mm 200
Width mm 750 950 1,150
Depth mm 620
Packed unit Height mm 260
Width mm 922 1,122 1,322
Depth mm 768
Weight Unit kg 22.0 26.0 29.0
Packed unit kg 24 25 28 29 33
Casing Colour Not painted (galvanised)
Material Galvanised steel
Heat exchanger Inside length mm 500 700 900
Rows Quantity 2 3
Fin pitch mm 1.50
Passes Quantity 3 6
Face area m² 0.126 0.176 0.227
Stages Quantity 12
Empty tubeplate
hole
Quantity 0 4 0
Tube type ø7 Hi-XD
Fin Type Symmetric waffle louvre
Fan Type Sirocco fan
Quantity 2 3
Air flow rate - 50Hz Cooling High m³/min 7.5 8.0 10.5 12.5 16.5
Low m³/min 6.4 8.5 10.0 13.0
External static
pressure - 50Hz
High Pa 30.0 44.0
Nom. Pa 10 15
External static
pressure - 60Hz
High Pa 30 44
Nom. Pa 10 15
Fan motor Quantity 1
Model KFD-280-44-8A KFD-280-65-8A
Air filter Type Removable / washable
Sound power level Cooling High dBA 50 51 52 53 54
Sound pressure level Cooling High dBA 32.0 33.0 34.0 35.0 36.0
Nom. dBA 31.0 32.0 33.0 34.0
Low dBA 27.0 28.0 29.0 30.0
Refrigerant Type R-410A
Control Electronic expansion valve
Piping connections Liquid Type Flare connection
OD mm 6,35 9,52
Gas Type Flare connection
OD mm 12.7 15.9
Drain VP20 (I.D. 20/O.D. 26)
Heat insulation Both liquid and gas pipes
Drain-up height mm 600
Safety devices Item 01 Fuse
02 Thermal protector for fan motor
Control systems Infrared remote control BRC4C65 / BRC4C66
Wired remote control BRC1D528 / BRC1E51
Simplified wired remote control for hotel
applications
-
