Mechanical SpecificationMechanical Specification
※ T case: Max. Case Temperature.
H05RN-F 1.0mm 2C
2
×
35
1500 50±
300 20±
H05RN-F 1.0mm 2C
2
×
53
2- 4.5ψ
130
5
5
5
5
85.5
31.5
Plug Assignment
60W Single Output Moistureproof Switching Adaptor
OWA-60E series
File Name:OWA-60E-SPEC 2015-01-04
Installation Manual
Please refer to : http://www.meanwell.com/webnet/search/InstallationSearch.html
Recommend Mounting Direction
-V not connected to AC FG
InsideOutside
ID 2.1 x OD 5.5
C"+"
11 0.5±
CASE NO.: OWA-60 Unit:mm
CEE 7/7
Standard plug: P1J
P/N
OUTPUT
P1J
CENTER
+
