MEAN WELL PCD-25-1050B [4/4] Series

AC Dimming Operation

Under direct driving, the power supply will work in "constant current mode (CC)" and output voltage of the power supply will be clamped by sum of

◎ The following diagram depicts a typical installation utilizing the PCD-25 :

forward voltage (V ) of the LED strip.

◎ Dimmer Compatibility Chart

Manufacturer

LUTRON

LEVITON

JUNG

BERKER

Bodo Ehmann LICHTREGLER

CLIPSAL

Conduction angle: 30 degrees(min.) / 180 degrees(max.)

Dimmer Model

SKYLARK SF-12P-277 (277VAC / 60Hz)

(277VAC / 60Hz)

(120VAC / 60Hz)

(230VAC / 50Hz)

(230-240VAC / 50Hz)

(230VAC / 50Hz)

(220-240VAC / 50Hz)

DVF-103P-277

SKYLARK SF-10P

SKYLARK S-600P

SKYLARK DVF-103P

ILLUMATECH TM Cat.No.IP106

SURESLIDE TM Cat.No.6633-P

SURESLIDE TM Cat. NO.6615-P

Licht-Management 225 TDE

Licht-Management 225 NV DE

Tronic-Drehdimmer 286710

T39.01

32E450UDM

NO 32E450TM

File Name:PCD-25-SPEC 2017-11-03

25W Single OutputAC Dimmable LED Power Supply

PCD-25 series

PCD-25

TRIAC

Based

Dimmer

Rated current
