MEAN WELL PCD-40-1050B [4/4] Series

File Name:PCD-40-SPEC 2017-11-03

40W Single OutputAC Dimmable LED Power Supply

PCD-40 series

AC Dimming Operation

PCD-40

TRIAC

Based

Dimmer

Under direct driving, the power supply will work in "constant current mode (CC)" and output voltage of the power supply will be clamped by sum of

◎ The following diagram depicts a typical installation utilizing the PCD-40 :

forward voltage (V ) of the LED strip.

◎ Dimmer Compatibility Chart

Manufacturer

LUTRON

JUNG

BERKER

CLIPSAL

Conduction angle: 30 degrees(min.) / 180 degrees(max.)

Dimmer Model

SKYLARK SF-12P-277 (277VAC / 60Hz)

(277VAC / 60Hz)

(230VAC / 50Hz)

(230-240VAC / 50Hz)

(220-240VAC / 50Hz)

DVF-103P-277

Licht-Management 225 TDE

Licht-Management 225 NV DE

Tronic-Drehdimmer 286710

32E450UDM

NO 32E450TM

CLIPSAL

(220-240VAC / 50Hz)

(230-240VAC / 50Hz)

NO 32E450LM

Cat 400T
