MEAN WELL PLC-30-36 [3/3] Plc 30

10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

230V

115V

0 .7 8

0 .8 0

0 .8 2

0 .8 4

0 .8 6

0 .8 8

0 .9 0

0 .9 2

0 .9 4

0 .9 6

0 .9 8

1 .0 0

5 0 % 6 0 % 7 0 % 8 0 % 9 0 % 1 0 0 %

2 3 0 V

1 1 5 V

Power Factor Characteristic

EFFICIENCY vs LOAD (48V Model)

PLC-30 series possess superior working efficiency that up to 85.5% can be reached in field applications.

Constant Current Mode

LOAD

EFFICIENCY (%)

LOAD

DRIVING METHODS OF LED MODULE

(30W)

This LED power supply is suggested to work in constant current mode area (CC) to drive the LEDs.

File Name:PLC-30-SPEC 2014-03-13

30W Single Output LED Power Supply

PLC-30 seri es

Typical LED power supply I-V curve

Vo(%)

100

50 100

(min.)

Io (%)

Constant

Current area

Hiccup

Protection

In the constant current region, the highest voltage at the output of the driver

depends on the configuration of the end systems.

Should there be any compatibility issues, please contact MEAN WELL.
