Zkteco PL-32C20D [2/4] Wall mount

1. Dimension

Pendant

Wall

P46

P66

P67

P68

2. Installation

2.1 Ceiling mount

1. Like picture 2.1-1, drill holes and fix bracket onto the ceiling floor with 4

pcs bolts.

Picture 2.1-1

2. Like picture 2.1-2, fasten the dome to the bracket with 3pcs bolts.

Picture 2.1-2

2.2 Wall mount

1. Like picture 2.2-1, drill holes and fix bracket onto the ceiling floor with 4

pcs bolts.

Picture 2.2-1

2. Like picture 2.2-2, fasten the dome to the bracket with 3pcs bolts.

Picture 2.2-2

3. Precaution

1. Please use the suitable power supply unit, power supply unit info

reference cable label or color box label.

2. The installation place must have enough weight tolerance

3. Under demanded environment, using this dome
