MEAN WELL PLM-25E-1050 [3/4] Series
![MEAN WELL PLM-25E-1050 [3/4] Series](/views2/1704530/page3/bg3.png)
Mechanical Specification
Case No.PLM-25 Unit:mm
25W Single Output LED Power Supply
PLM-25 series
File Name:PLM-25-SPEC 2018-01-10
LOAD (%)LOAD (%)
Block Diagram
AMBIENT TEMPERATURE ( )℃
LOAD (%)
Derating CurveDerating Curve
Static Characteristics
INPUT VOLTAGE (V)
LOAD (%)
(HORIZONTAL)
PWM /PFC
EMI FILTER
POWER
SWITCH-
FILTER
&
RECTIFIERS
+V
-V
I/P
ING
CONTROL
RECTIFIERS
65
Tcase
12
T case: Max. Case Temperature.
145
38
22
3.5
ψ
3.5
4.5
4.5
4.5
4.5
NOTE: The input and output line for using UL1015 18AWG*2C is suggested
1
2
2
1
Terminal Pin No. Assignment (TB1) :
SWITCHLAB MWX201-75002EB(GRAY)
Terminal Pin No. Assignment (TB2) :
SWITCHLAB MWX201-75002B(BLUE)
Pin No. Pin No.
11
22
Assignment Assignment
AC/N -V
AC/L +V
TB1
TB2
110 120 125 135 145 155 165 175 180 200 230 295
100
90
80
70
60
50
40
180 185 190 195 200 205 210 220 230 240 295215
(Blank type)
(E type)
-25 -5 0 15 30
20
40
60
80
100
-25 -5 0 15 30 40 50
20
40
60
80
100
-30 60
45
