MODEL

PLM-40 -1400

PLM-40 -1750

PLM-40 -1050PLM-40 -700

PLM-40 -500

RATED CURRENT

CURRENT ACCURACY

Note.3

OPERATING VOLTAGE RANGE Note.5

RATED POWER

OUTPUT

SETUP TIME

FREQUENCY RANGE

POWER FACTOR

(Typ.)

EFFICIENCY (Typ.)

AC CURRENT (Typ.)

INPUT

INRUSH CURRENT(Typ.)

LEAKAGE CURRENT

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

SHORT CIRCUIT

OVER TEMPERATURE

1400mA

1750mA

1050mA700mA

500mA

40.6W

40.25W

39.9W39.9W

40W

3Vp-p

2.5Vp-p

4Vp-p6Vp-p

8Vp-p

47 ~ 63Hz

86%

87%87%

88%

Blank Type: E Type:0.5A/115VAC 0.3A/230VAC 0.25A/277VAC 0.3A/230VAC 0.25A/277VAC

<0.5mA / 240VAC

Hiccup mode, recovers automatically after fault condition is removed.

-30 ~ +40 (Refer to "Derating Curve")℃

20 ~ 95% RH non-condensing

-40 ~ +80 , 10 ~ 95% RH℃

±℃ ℃0.06%/ (0 ~ 40 )

10 ~ 500Hz, 2G 12min./1cycle, period for 72min. each along X, Y, Z axes

822.7Khrs min. MIL-HDBK-217F (25 )℃

175*42*24mm (L*W*H)

0.175Kg; 60pcs/11.5kg/0.68CUFT

RIPPLE & NOISE (max.) Note.2

ENVIRONMENT

SAFETY &

EMC

PROTECTION

Hiccup mode, recovers automatically after temperature goes down.

SAFETY STANDARDS

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:3.75KVAC

I/P-O/P:100M Ohms / 500VDC / 25 / 70% RH℃

Compliance to EN55015, ,EN61000-3-2 Class C ; EN61000-3-3GB17743, GB17625.1 ( 75% load) EAC TP TC 020≧ ,

Compliance to EN61000-4-2,3,4,5,6,8,11 EN61547, light industry level, criteria B (Surge 2KV), EAC TP TC 020,

29 ~ 57V

40 ~ 80V

15 ~ 29V

12 ~ 23V

19 ~ 38V

File Name:PLM-40-SPEC 2018-05-02

63V

86V

43V

34V

27V

NO LOAD OUTPUT VOLTAGE (max.)

EMC IMMUNITY

EMC EMISSION

VOLTAGE RANGE Note.4

PLM-40 -350

350mA

36.75W

10Vp-p

88%

53 ~ 105V

115V

±8.0%

COLD START 15A(twidth=75 s measured at 50% Ipeak) at 230VACμ

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Please see AC input voltage drop vs. output current characteristics table.""

4. Derating may be needed under low input voltage, please check the static characteristic for more details.

5. Constant current operation region is within 50% ~100% rated output voltage. This is the suitable operation region for LED related applications, but please

reconfirm special electrical requirements for some specific system design.

6. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the

complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.

7. Direct connecting to LEDs is suggested, but is not suitable for using additional drivers.

8. The ambient temperature derating of 3.5 /1000m with fanless models and of 5 /1000m with fan models for operating altitude higher than 2000m(6500ft)℃℃ .

UL8750, CSA C22.2 No. 250.13-12;ENEC EN61347-1, EN61347-2-13, EN62384, IP30 approvedGB19510.14,GB19510.1 EAC TP TC 004,

TOTAL HARMONIC

DISTORTION

Blank type

E type

SPECIFICATION

40W Single Output LED Power Supply

PLM-40 series

Blank type

E type

Blank Type: 500ms /115VAC, 230VAC at full load; E Type: 500ms / 230VAC at full load

Blank Type: E Type:110 ~ 295VAC 156 ~ 417VDC; 180 ~ 295VAC 254 ~ 417VDC

PF 0.97/115VAC,PF 0.95/230VAC,PF>0.9/277VAC(at full load)≥≥ (Please refer to "Power Factor Characteristic" curve)

PF 0.95/230VAC,PF>0.9/277VAC(at full load)(Please refer to "Power Factor Characteristic" curve)≥

THD< 20% when output loading 60% at 115VAC/230VAC input and output loading 75% at 277VAC input≧≧

THD< 20% when output loading 60% at 230VAC input and output loading 75% at 277VAC input≧≧

MAX. No. of PSUs on 16A

CIRCUIT BREAKER

47 units (circuit breaker of type B) / 47 units (circuit breaker of type C) at 230VAC
