Development history
To meet the needs of the times, we've continued to develop technology
continuously as the leading air conditioning manufacturer in the world.
General Catalogue
02
Background of VRV development
VRV series released in 1982
<The birth of innovative products that changed the history of air conditioning technology>
’82
’84
’88
’90
’92
’95
’96
’99
’02
’00
’04
’05
’06
’07
’08
’10
’11
’12
’16
’14
2.5 years development term
Completion of development in May, 1982
Technical award of Japan Society of
Refrigerating & Air-conditioning
Engineers in 1983
Conceptual diagram of a multi air conditioner for buildings
VRV C series
-Cooling only-
VRV D series
-Cooling only-
VRV G series
-Heat pump-
VRV G series
-Heat recovery-
VRV II MA
series
VRV L series
Adopted the new
R-407C refrigerant
VRV III-C series
-Low outdoor temp.
area use-
VRV III Q series
-Replacement use-
VRV Multi
function series
-Cooling/heating,
hot water supply-
VRV II M series
VRV III
series
Adopted the new
R-410A refrigerant
VRV H series
Made possible to
connect to BMS
using the DIII-NET
VRV K series
VRV K Plus series
VRV KA series
VRV F series
-Cooling only-
VRV II-S
series
VRV III-S series
VRV-WII series
VRV-WIII series
VRV III Connection
to residential
indoor unit series
-Heat recovery-
VRV IV
VRV IV S series
-Cooling only /
Heat pump-
VRV IV
The 1st Generation
01
*
VRV is a trademark of Daikin Industries, Ltd.
VRV IV W series
-Water Cooled system-
