MEAN WELL PLP-60-48 [2/3] Block diagram

Mechanical Specification

File Name:PLP-60-SPEC 2015-02-12

Unit:mm

Derating Curve Static Characteristics

AMBIENT TEMPERATURE ( )℃

-30 -25 -5 0 20 40 50 55 60 70

100

INPUT VOLTAGE (V) 60Hz

90 100 125 135 145 155 165 175 180 200 230 264

100

(HORIZONTAL)

fosc : 90KHz(115VAC)

120KHz(230VAC)

Block Diagram

AC Input Connector (CN1) : JST B3P-VH or equivalent

DC Output Connector (CN2) : JST B2P-VH or equivalent

Pin No.

Pin No.1

3 2

Assignment

AssignmentAC/L

AC/N -V

No Pin

Mating Housing

JST VHR

or equivalent

Terminal

JST SVH-21T-P1.1

or equivalent

12V

Others

: Grounding required

DETECTION

PWM & PFC

CIRCUIT

O.L.P.

EMI FILTER

RECTIFIERS

POWER

SWITCHING

FILTER

RECTIFIERS

-V

I/P

CONTROL

O.V.P.

O.C.P.

CN2

CN1

FS1

3.175

95.25

101.6

HS2HS1

SVR1

PLP-60

seri e s

60W Single Output LED Power Supply

1.HS1,HS2 can not be shorted.

2.HS1 must have safety isolation distance

with system case.
