Design refer to EN61347-2-13,IEC61347-2-13,UL8750

‧Universal AC input / Full range(up to 295VAC)

‧Built in active PFC compliance to EN61000-3-2 class C

‧Constant Voltage design

‧High efficiency up to 93%

‧Protections: Short circuit / Overload / Over voltage / Over temperature

‧Cooling by free air convection

‧Half encapsulated

‧U-bracket low profile:33mm

‧ZVS technology to reduce power dissipation

‧Suitable for built-in type LED applications

‧3 years warranty

215*67.4*33mm (L*W*H)

150W

151.2W

153.6W

RATED POWER

151.2W

11.0~13.2V

13.5~16.5V

21.6~26.4V

43.2~52.8V

VOLTAGE ADJ. RANGE

32.4~39.6V

130~185% rated output power

SPECIFICATION

MODEL

DC VOLTAGE

RATED CURRENT

OUTPUT

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

VOLTAGE RANGE Note.4

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

OVER TEMPERATURE

SAFETY STANDARDS

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSION

OTHERS

NOTE

PACKING

OVERLOAD

OVER VOLTAGE

AC CURRENT (Typ.)

500ms, 100ms/230VAC 3000ms, 100ms/115VAC at full load

90 ~ 295VAC 127 ~ 417VDC

47 ~ 63Hz

2A/115VAC 1A/230VAC 0.7A/277VAC

COLD START 65A(twidth=460 s measured at 50% Ipeak) at 230VACμ

<0.75mA / 277VAC

13.6 ~ 16.3V

17 ~ 21V

26.7 ~ 32.4V

53 ~ 64.8V

Protection type : Hiccup mode, recovers automatically after fault condition is removed

Protection type : Shut down o/p voltage with auto-recovery or re-power on to recovery

Shut down o/p voltage, recovers automatically after temperature goes down

Compliance to EN55015, EN61000-3-2 Class C( 60% load),EN61000-3-3≥

-30 ~ +70℃ (Refer to "Derating Curve")

20 ~ 90% RH non-condensing

-40 ~ +85℃, 10 ~ 95% RH

±0.03%/℃ (0 ~ 60℃)

10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes

216.3K hrs min. MIL-HDBK-217F (25℃)

91.5%

PF>0.98/115VAC PF>0.96/230VAC PF>0.94/277VAC at full load

16ms/230VAC 16ms/115VAC at full load

91.5%

93%

±1.0%

±0.5%

±2.0%

100mVp-p

150mVp-p

250mVp-p

12V

12.5A

0 ~ 12.5A

15V

10A

0 ~ 10A

24V

6.3A

0 ~ 6.3A

48V

3.2A

0 ~ 3.2A

ULP-150-12

ULP-150-15

ULP-150-24

ULP-150-48

File Name:ULP-150-SPEC 2014-03-26

■ Features :

ULP-150 series

RIPPLE & NOISE (max.) Note.2

VOLTAGE TOLERANCE Note.3

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. Derating may be needed under low input voltages. Please check the static characteristics for more details.

5. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

6. Please remove the component D1 before conducted Hipot test.

7. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED power supply can only be used behind a switch without permanently

connected to the mains.

ENVIRONMENT

SAFETY &

EMC

(Note 5)

PROTECTION

WITHSTAND VOLTAGE Note.6

ISOLATION RESISTANCE

I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC/ 70%RH25℃/

CURRENT RANGE

41.4 ~ 48.6V

93%

±1.0%

±0.5%

±2.0%

250mVp-p

36V

4.2A

0 ~ 4.2A

ULP-150-36

150W U-Bracket Single Output with PFC Function

Compliance to EN61000-4-2,3,4,5,6,8,11; EN61547, EN55024, light industry level (surge 4KV), criteria A

SHORT CIRCUIT

Protection type : Hiccup mode, recovers automatically after fault condition is removed

0.67kg; 24PCS/17.5kg/0.65CUFT

EMC IMMUNITY

EMC EMISSION
