![MEAN WELL XBG-240-AB-C [3/8] Xbg 24](/img/pdf.png)
MEAN WELL XBG-240-AB-C [3/8] Xbg 24
![MEAN WELL XBG-240-AB-C [3/8] Xbg 24](/views2/1705225/page3/bg3.png)
BLOCK DIAGRAM
PFC fosc : 45~50KHz
PWM fosc : 60~130KHz
4000mA,60V
5700mA,42V
5700mA,30V
4000mA,30V
2000mA,60V
25V
30V
35V
40V
45V
50V
55V
60V
65V
0mA 1000mA 2000mA 3000mA 4000mA 5000mA 6000mA
240W Constant Power Mode LED Driver
XBG-240 series
File Name:XBG-240-SPEC 2020-11-16
(AB Type)
DETECTION
PWM
CIRCUIT/OTP
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
PE
CONTROL
O.V.P.
&
PFC
CIRCUIT
PFC
CONTROL
DRIVING METHODS OF LED MODULE
※ -I V Operating Area
◎ XBG-240
High Performance Region
DIM+
DIM-
O.C.P.
