![Daikin FXLQ63P2VEB [10/19] Capacity tables](/views2/1705282/page10/bga.png)
• Indoor Unit • FXLQ-P
6
• VRV Systems • FXLQ-P
8
6 Capacity tables
6 - 1 Cooling Capacity Tables
Unit size
Indoor air temp.
14.0 °CWB 16.0 °CWB 18.0 °CWB 19.0 °CWB 20.0 °CWB 22.0 °CWB 24.0 °CWB
20.0 °CDB 23.0 °CDB 26.0 °CDB 27.0 °CDB 28.0 °CDB 30.0 °CDB 32.0 °CDB
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
20 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.7 2.4 1.6 2.4 1.5
25 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.0 2.0 3.1 1.9
32 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.5 3.9 2.4 4.0 2.3
40 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.7 3.2 4.9 3.1 5.0 2.9
50 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 5.9 4.0 6.0 3.8 6.2 3.6
63 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.5 4.9 7.7 4.7 7.8 4.3
FXLQ-P
TC: Total capacity; kW
SHC: Sensible heat capacity; kW
