Daikin BEVQ125MVE [72/352] Cooling oil return operation
![Daikin BEVQ125MVE [72/352] Cooling oil return operation](/views2/1705708/page72/bg48.png)
Si39-407 Refrigerant Flow for Each Operation Mode
Refirgerant Circuit 61
Cooling Oil Return Operation
Thermostat "OFF"
" OFF " " ON "
" ON "
FanFan
Indoor unit operation
Fan OFF
Indoor unit
Electronic expansion valve
EV:200pls
FilterFilter
Heat exchanger
Fan OFF
Indoor unit
Electronic expansion valve
EV:200pls
FilterFilter
Heat exchanger
Fan ON
Thermostat "ON"
Indoor unit
"High temperature, high pressure gas"
"High temperature, high pressure liquid"
"Low temperature, low pressure"
Heat exchanger
Electronic expansion valve
EV:Nomal
control
FilterFilter
Fan
Heat
exchanger pipe
Receiver
Solenoid
valve
Filter
Capillary
tube
4-way valve
Gauge port
High pressure
sensor
High pressure
switch
Solenoid
valve
Gauge port
Stop valve(with service port on on-site piping side
φ
7.9 flare connection)
Low pressure
sensor
FilterFilter
Filter
Capillary tube
Compressor
Oil separator
Pressure regulating
valve
(check valve type)
Solenoid
valve
Filter
Filter
Filter
Electronic
expansion valve
Fusible plug
