75W Constant Power Mode LED Driver
XLG-75 series
File Name:XLG-75-SPEC 2019-04-10
MECHANICAL SPECIFICATION
Case No.: 275A Unit:mm
※ Blank-Type
4-Φ4.5
134
140
125
32
300±20
300±20
• : Max. Case Temperature
tc
40
63
SJOW 17AWGx3C
2
&H05RN-F 3x1.0mm
AC/L(Brown)
AC/N(Blue)
FG(Green/Yellow)
Vo+(Red)
Vo-(Black)
Vo+(Red)
Vo-(Black)
SJOW 17AWGx2C
2
&05RN-F 2x1.0mm
Vo+(Red)
Vo-(Black)
24
tc
57
※ A-Type
4-Φ4.5
134
140
125
39.7
12.7
32
300±20
300±20
• : Max. Case Temperature
tc
40
63
SJOW 17AWGx3C
2
&H05RN-F 3x1.0mm
AC/L(Brown)
AC/N(Blue)
FG(Green/Yellow)
Vo+(Red)
Vo-(Black)
Vo+(Red)
Vo-(Black)
SJOW 17AWGx2C
2
&05RN-F 2x1.0mm
Vo+(Red)
Vo-(Black)
24
tc
57
