• Наружные блоки • Сочетание систему рекуперации тепла VRV® с малой площадью, необходимой для установки оборудования • REYQ8-48P8/P9
4 Таблицы мощности
4 - 2 Таблицы мощности, охлаждение
1
4
REYQ24P8
4TW31482-1A
NOTES
-
ANMERKUNGEN
- ƴLjǍdžNJǟǔdžNJǓ -
NOTAS
-
REMARQUES
-
NOTE
-
OPMERKINGEN
- ȝȞȖȚȓȥȎțȖȭ -
NOTLAR
1
The above table shows the average value of conditions which may occur.
Die obige Tabelle zeigt den Durchschnittswert der Bedingungen, die auftreten können.
ȈIJȠȞ ʌĮȡĮʌȐȞȦ ʌȓȞĮțĮ ĮȞĮȖȡȐijİIJĮȚ Ș ȝȑıȘ IJȚȝȒ ȖȚĮ ıȣȞșȒțİȢ ʌȠȣ ȝʌȠȡİȓ ȞĮ ʌȡȠțȪȥȠȣȞ.
La tabla de arriba muestra el valor medio de condiciones que pueden ocurrir.
Le tableau ci-dessus donne la valeur moyenne pour des conditions qui peuvent survenir.
La tabella in alto mostra il valore delle condizioni medie che si possono riscontrare.
De tabel hierboven geeft de gemiddelde waarde aan van situaties die kunnen voorvallen.
Ɍɚɛɥɢɰɚ ɪɚɫɩɨɥɨɠɟɧɧɚɹ ɜɵɲɟ ɩɨɤɚɡɵɜɚɟɬ ɫɪɟɞɧɟɟ ɡɧɚɱɟɧɢɟ ɭɫɥɨɜɢɣ, ɤɨɬɨɪɵɟ ɦɨɝɭɬ ɧɚɫɬɭɩɢɬɶ.
Yukarıdaki tablo meydana gelebilecek koúulların ortalama de÷erini göstermektedir.
TC: Total Capacity: kW ; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacity
index
(kW)
Outdoor
air temp.
(°CDB)
Indoor air temperature:
14.0 °CWB 16.0 °CWB 18.0 °CWB 19.0 °CWB 20.0 °CWB 22.0 °CWB 24.0 °CWB
20.0 °CDB 23.0 °CDB 26.0 °CDB 27.0 °CDB 28.0 °CDB 30.0 °CDB 32.0 °CDB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 780
(87.10)
10 58.8 8.84 70.1 10.8 81.4 12.9 84.4 12.9 85.4 12.9 87.6 12.9 89.7 12.9
12 58.8 9.00 70.1 11.0 81.4 13.1 83.3 13.1 84.4 13.1 86.5 13.1 88.6 13.1
14 58.8 9.17 70.1 11.2 81.1 13.3 82.2 13.3 83.3 13.3 85.4 13.3 87.5 13.3
16 58.8 9.35 70.1 11.5 80.1 13.2 81.1 13.3 82.2 13.3 84.3 13.3 86.4 13.3
18 58.8 9.53 70.1 11.7 79.0 13.7 80.0 13.8 81.1 13.9 83.2 14.0 85.3 14.1
20 58.8 9.72 70.1 12.4 77.9 14.4 78.9 14.5 80.0 14.5 82.1 14.7 84.2 14.8
21 58.8 10.00 70.1 12.9 77.3 14.7 78.4 14.8 79.5 14.9 81.6 15.0 83.7 15.2
23 58.8 10.7 70.1 13.8 76.2 15.4 77.3 15.5 78.4 15.6 80.5 15.7 82.6 15.9
25 58.8 11.4 70.1 14.8 75.2 16.1 76.2 16.2 77.3 16.2 79.4 16.4 81.5 16.6
27 58.8 12.2 70.1 15.8 74.1 16.7 75.1 16.8 76.2 16.9 78.3 17.1 80.4 17.3
29 58.8 13.0 70.1 16.9 73.0 17.4 74.0 17.5 75.1 17.6 77.2 17.8 79.3 18.0
31 58.8 13.9 69.8 17.9 71.9 18.1 72.9 18.2 74.0 18.3 76.1 18.5 78.2 18.7
33 58.8 14.8 68.7 18.6 70.8 18.8 71.9 18.9 72.9 19.0 75.0 19.2 77.2 19.4
35 58.8 15.8 67.6 19.3 69.7 19.5 70.8 19.6 71.8 19.7 73.9 19.9 76.1 20.1
37 58.8 16.8 66.5 19.9 68.6 20.2 69.7 20.3 70.7 20.4 72.9 20.6 75.0 20.9
39 58.8 17.9 65.4 20.6 67.5 20.9 68.6 21.0 69.6 21.1 71.8 21.4 73.9 21.6
120 720
(80.40)
10 54.3 8.08 64.7 9.87 75.2 11.7 80.4 12.7 84.1 12.7 86.1 12.7 88.0 12.7
12 54.3 8.23 64.7 10.1 75.2 12.0 80.4 12.9 83.0 12.9 85.0 12.9 86.9 12.9
14 54.3 8.38 64.7 10.2 75.2 12.2 80.4 13.2 81.9 13.2 83.9 13.2 85.8 13.2
16 54.3 8.54 64.7 10.4 75.2 12.4 79.9 13.3 80.8 13.3 82.8 13.3 84.8 13.3
18 54.3 8.70 64.7 10.7 75.2 12.8 78.8 13.7 79.8 13.8 81.7 13.9 83.7 14.0
20 54.3 8.87 64.7 11.1 75.2 13.8 77.7 14.4 78.7 14.4 80.6 14.6 82.6 14.7
21 54.3 8.96 64.7 11.5 75.2 14.3 77.1 14.7 78.1 14.8 80.1 14.9 82.0 15.1
23 54.3 9.57 64.7 12.3 75.1 15.3 76.0 15.4 77.0 15.5 79.0 15.6 80.9 15.7
25 54.3 10.2 64.7 13.1 74.0 16.0 75.0 16.1 75.9 16.1 77.9 16.3 79.8 16.4
27 54.3 10.9 64.7 14.1 72.9 16.7 73.9 16.7 74.8 16.8 76.8 17.0 78.8 17.1
29 54.3 11.6 64.7 15.0 71.8 17.3 72.8 17.4 73.8 17.5 75.7 17.7 77.7 17.8
31 54.3 12.4 64.7 16.0 70.7 18.0 71.7 18.1 72.7 18.2 74.6 18.4 76.6 18.5
33 54.3 13.2 64.7 17.1 69.6 18.7 70.6 18.8 71.6 18.9 73.5 19.1 75.5 19.3
35 54.3 14.1 64.7 18.2 68.5 19.4 69.5 19.5 70.5 19.6 72.4 19.8 74.4 20.0
37 54.3 15.0 64.7 19.4 67.4 20.0 68.4 20.2 69.4 20.3 71.4 20.5 73.3 20.7
39 54.3 15.9 64.4 20.5 66.4 20.7 67.3 20.8 68.3 21.0 70.3 21.2 72.2 21.4
110 660
(73.70)
10 49.7 7.34 59.3 8.93 68.9 10.6 73.7 11.5 78.5 12.3 84.6 12.6 86.4 12.6
12 49.7 7.47 59.3 9.10 68.9 10.8 73.7 11.7 78.5 12.6 83.5 12.9 85.3 12.9
14 49.7 7.60 59.3 9.27 68.9 11.0 73.7 11.9 78.5 12.8 82.4 13.1 84.2 13.1
16 49.7 7.74 59.3 9.45 68.9 11.2 73.7 12.1 78.5 13.1 81.3 13.3 83.1 13.3
18 49.7 7.89 59.3 9.63 68.9 11.5 73.7 12.5 78.4 13.7 80.2 13.8 82.0 13.9
20 49.7 8.05 59.3 9.83 68.9 12.1 73.7 13.4 77.3 14.4 79.1 14.5 80.9 14.6
21 49.7 8.12 59.3 10.1 68.9 12.6 73.7 13.9 76.8 14.7 78.6 14.8 80.4 14.9
23 49.7 8.50 59.3 10.8 68.9 13.5 73.7 14.9 75.7 15.4 77.5 15.5 79.3 15.6
25 49.7 9.08 59.3 11.6 68.9 14.4 73.7 16.0 74.6 16.0 76.4 16.2 78.2 16.3
27 49.7 9.69 59.3 12.4 68.9 15.4 72.6 16.6 73.5 16.7 75.3 16.9 77.1 17.0
29 49.7 10.3 59.3 13.2 68.9 16.5 71.5 17.3 72.4 17.4 74.2 17.5 76.0 17.7
31 49.7 11.0 59.3 14.1 68.9 17.6 70.4 18.0 71.3 18.1 73.1 18.2 74.9 18.4
33 49.7 11.7 59.3 15.0 68.4 18.6 69.3 18.7 70.2 18.7 72.0 18.9 73.8 19.1
35 49.7 12.5 59.3 16.0 67.4 19.2 68.3 19.3 69.2 19.4 70.9 19.6 72.7 19.8
37 49.7 13.2 59.3 17.1 66.3 19.9 67.2 20.0 68.1 20.1 69.9 20.3 71.6 20.5
39 49.7 14.1 59.3 18.2 65.2 20.6 66.1 20.7 67.0 20.8 68.8 21.0 70.6 21.2
100 600
(67.00)
10 45.2 6.62 53.9 8.02 62.6 9.51 67.0 10.3 71.4 11.0 80.1 12.6 84.7 12.6
12 45.2 6.73 53.9 8.17 62.6 9.68 67.0 10.5 71.4 11.3 80.1 12.9 83.6 12.9
14 45.2 6.85 53.9 8.32 62.6 9.87 67.0 10.7 71.4 11.5 80.1 13.1 82.5 13.1
16 45.2 6.98 53.9 8.48 62.6 10.1 67.0 10.9 71.4 11.7 79.8 13.3 81.4 13.3
18 45.2 7.11 53.9 8.64 62.6 10.3 67.0 11.1 71.4 11.9 78.7 13.7 80.3 13.8
20 45.2 7.24 53.9 8.81 62.6 10.6 67.0 11.6 71.4 12.8 77.6 14.4 79.3 14.5
21 45.2 7.31 53.9 8.90 62.6 10.9 67.0 12.1 71.4 13.2 77.1 14.7 78.7 14.8
23 45.2 7.50 53.9 9.49 62.6 11.7 67.0 12.9 71.4 14.2 76.0 15.4 77.6 15.5
25 45.2 8.01 53.9 10.1 62.6 12.5 67.0 13.8 71.4 15.2 74.9 16.1 76.5 16.2
27 45.2 8.53 53.9 10.8 62.6 13.4 67.0 14.8 71.4 16.3 73.8 16.7 75.4 16.9
29 45.2 9.09 53.9 11.5 62.6 14.3 67.0 15.8 71.1 17.3 72.7 17.4 74.3 17.5
31 45.2 9.67 53.9 12.3 62.6 15.3 67.0 16.9 70.0 17.9 71.6 18.1 73.3 18.2
33 45.2 10.3 53.9 13.1 62.6 16.3 67.0 18.0 68.9 18.6 70.5 18.8 72.2 18.9
35 45.2 10.9 53.9 14.0 62.6 17.4 67.0 19.2 67.8 19.3 69.4 19.5 71.1 19.6
37 45.2 11.6 53.9 14.8 62.6 18.5 65.9 19.9 66.7 20.0 68.4 20.1 70.0 20.3
39 45.2 12.3 53.9 15.8 62.6 19.7 64.8 20.6 65.6 20.7 67.3 20.8 68.9 21.0
