SiENBE37-704 Specifications
Specifications 21
1.2 Indoor Units
Roundflow Ceiling Mounted Cassette
1-1 TECHNICAL SPECIFICATIONS FXFQ20PVEB FXFQ25PVEB FXFQ32PVEB FXFQ40PVEB FXFQ50PVEB
Capacity Cooling kW 2.2 2.8 3.6 4.5 5.6
Heating kW 2.5 3.2 4.0 5.0 6.3
Power Input Cooling kW 0.053 0.053 0.053 0.063 0.083
Heating kW 0.045 0.045 0.045 0.055 0.067
Casing Material Galvanised steel
Dimensions Packing Height mm 220 220 220 220 220
Width mm 882 882 882 882 882
Depth mm 882 882 882 882 882
Unit Height mm 204 204 204 204 204
Width mm 840 840 840 840 840
Depth mm 840 840 840 840 840
Weight Unit kg 20.0 20.0 20.0 20.0 21.0
Packed Unit kg 24.0 24.0 24.0 24.0 26.0
Dimensions Length Inside mm 2,096
Outside mm 2,152
Heat
Exchanger
Dimensions
Nr of Rows 2 2 2 2 2
Fin Pitch mm 1.2 1.2 1.2 1.2 1.2
Nr of Passes 2 2 3 3 7
Face Area m² 0.267 0.267 0.267 0.267 0.357
Nr of Stages 6 6 6 6 8
Empty Tubeplate
Hole
4 4
Fin Fin type Cross fin coil (Multi louver fins and Hi-XSS tubes)
Fan Type Turbo fan
Quantity 1 1 1 1 1
Air Flow
Rate
Cooling High m³/min 12.5 12.5 12.5 13.5 15.5
Low m³/min 9.0 9.0 9.0 9.0 10.0
Heating High m³/min 12.5 12.5 12.5 13.5 15.0
Low m³/min 9.0 9.0 9.0 9.0 9.5
Fan Motor Model QTS48D11M
Steps 2 2 2 2 2
Output
(high)
W 56 56 56 56 56
Refrigerant Name R-410A
Sound Level Cooling Sound
power
(nominal)
dBA 49 49 49 50 51
Cooling Sound
Pressure
High dBA 31 31 31 32 33
Low dBA 28 28 28 28 28
Heating Sound
Pressure
High dBA 31 31 31 32 33
Low dBA 28 28 28 28 28
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.35 6.4 6.4 6.4 6.4
Gas Type Flare connection
Diameter mm 12.7 12.7 12.7 12.7 12.7
Drain Diameter mm VP25 (I.D. 25/O.D. 32)
Heat Insulation Foamed polystyrene/polyethylene
Sound absorbing insulation (Foamed Polyurethane)
Decoration
Panel
Model BYCQ140CW1
Colour RAL9010
Dimensions
Height mm 50 50 50 50 50
Width mm 950 950 950 950 950
Depth mm 950 950 950 950 950
Weight kg 5.5 5.5 5.5 5.5 5.5
Air Filter Resin net with mold resistance
