Specifications SiENBE37-704
22 Specifications
Roundflow Ceiling Mounted Cassette
1-1 TECHNICAL SPECIFICATIONS FXFQ20PVEB FXFQ25PVEB FXFQ32PVEB FXFQ40PVEB FXFQ50PVEB
Standard
Accessories
Standard Accessories Installation and operation manual
Drain hose
Washer for hanging bracket
Screws
Sealing Pads
Insulation for fitting
Clamp for drain hose
Installation guide
Drain sealing pad
Notes The sound pressure values are mentioned for a unit installed with rear suction
The sound power level is an absolute value indicating the power wich a sound source generates.
Nominal cooling capacities are based on: indoor temperature: 27°CDB,19°CWB, outdoor temperature: 35°CDB,
equivalent refrigerant piping: 5m, level difference: 0m.
Nominal heating capacities are based on: indoor temperature: 20°CDB, outdoor temperature: 7°CDB, 6°CWB,
equivalent refrigerant piping : 5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
1-1 TECHNICAL SPECIFICATIONS FXFQ63PVEB FXFQ80PVEB FXFQ100PVEB FXFQ125PVEB
Capacity Cooling kW 7.1 9.0 11.2 14.0
Heating kW 8.0 10.0 12.5 16.0
Power Input Cooling kW 0.095 0.120 0.173 0.258
Heating kW 0.114 0.108 0.176 0.246
Casing Material Galvanised steel
Dimensions Packing Height mm 220 262 262 304
Width mm 882 882 882 882
Depth mm 882 882 882 882
Unit Height mm 204 246 246 288
Width mm 840 840 840 840
Depth mm 840 840 840 840
Weight Unit kg 21.0 24.0 24.0 26.0
Packed Unit kg 26.0 28.0 28.0 31.0
Dimensions Length Inside mm 2,096
Outside mm 2,152
Heat
Exchanger
Dimensions
Nr of Rows 2 2 2 2
Fin Pitch mm 1.2 1.2 1.2 1.2
Nr of Passes 7 9 9 11
Face Area m² 0.357 0.446 0.446 0.535
Nr of Stages 8 10 10 12
Fin Fin type Cross fin coil (Multi louver fins and Hi-XSS tubes)
Fan Type Turbo fan
Quantity 1 1 1 1
Air Flow
Rate
Cooling High m³/min 16.5 23.5 26.5 33.0
Low m³/min 11.0 14.5 17.0 20.0
Heating High m³/min 17.5 23.5 28.0 33.0
Low m³/min 12.0 14.5 17.5 20.0
Fan Motor Model QTS48D11M QTS48C15M QTS48C15M QTS48C15M
Steps 2 2 2 2
Output
(high)
W 56 120 120 120
Refrigerant Name R-410A
Sound Level Cooling Sound
power
(nominal)
dBA 52 55 58 61
Cooling Sound
Pressure
High dBA 34 38 41 44
Low dBA 29 32 33 34
Heating Sound
Pressure
High dBA 36 38 42 44
Low dBA 30 32 34 34
