SiENBE37-704 Specifications
Specifications 23
Roundflow Ceiling Mounted Cassette
1-1 TECHNICAL SPECIFICATIONS FXFQ63PVEB FXFQ80PVEB FXFQ100PVEB FXFQ125PVEB
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 9.5 9.5 9.5 9.5
Gas Type Flare connection
Diameter mm 15.9 15.9 15.9 15.9
Drain Diameter mm VP25 (I.D. 25/O.D. 32)
Heat Insulation Foamed polystyrene/polyethylene
Sound absorbing insulation (Foamed Polyurethane)
Decoration
Panel
Model BYCQ140CW1
Colour RAL9010
Dimensions
Height mm 50 50 50 50
Width mm 950 950 950 950
Depth mm 950 950 950 950
Weight kg 5.5 5.5 5.5 5.5
Air Filter Resin net with mold resistance
Standard
Accessories
Standard Accessories Installation and operation manual
Drain hose
Washer for hanging bracket
Screws
Sealing Pads
Insulation for fitting
Clamp for drain hose
Installation guide
Drain sealing pad
Notes The sound pressure values are mentioned for a unit installed with rear suction
The sound power level is an absolute value indicating the power wich a sound source generates.
Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
