SiENBE37-704 Specifications
Specifications 25
600×600 4-Way Blow Ceiling Mounted Cassette
1-1 TECHNICAL SPECIFICATIONS FXZQ20MV1B FXZQ25MV1B FXZQ32MV1B FXZQ40MV1B FXZQ50MV1B
Nominal
Capacity
Cooling kW 2.20 2.80 3.60 4.50 5.60
Heating kW 2.50 3.20 4.00 5.00 6.30
Power input
(Nominal)
Cooling kW 0.073 0.073 0.076 0.089 0.115
Heating kW 0.064 0.064 0.068 0.080 0.107
Casing Material Galvanised steel
Dimensions Unit Height mm 286 286 286 286 286
Width mm 575 575 575 575 575
Depth mm 575 575 575 575 575
Weight Unit kg 18 18 18 18 18
Heat
Exchanger
Dimensions
Nr of Rows 2 2 2 2 2
Fin Pitch mm 1.50 1.50 1.50 1.50 1.50
Face Area m² 0.269 0.269 0.269 0.269 0.269
Nr of Stages 10 10 10 10 10
Fan Type Turbo fan
Quantity 1 1 1 1 1
Air Flow
Rate
Cooling High m³/min 9.00 9.00 9.50 11.00 14.00
Low m³/min 7.00 7.00 7.50 8.00 10.00
Fan Motor Quantity 1 1 1 1 1
Model QTS32C15M
Output
(high)
W 55 55 55 55 55
Drive Direct drive
Refrigerant Name R-410A
Sound Level Cooling Sound
power
(nominal)
dBA 47.0 47.0 49.0 53.0 58.0
Cooling Sound
Pressure
High dBA 30.0 30.0 32.0 36.0 41.0
Low dBA 25.0 25.0 26.0 28.0 33.0
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.4 6.4 6.4 6.4 6.4
Gas Type Flare connection
Diameter mm 12.7 12.7 12.7 12.7 12.7
Drain Diameter mm 26 26 26 26 26
Heat Insulation Foamed polystyrene/polyethylene
Decoration
Panel
Model BYFQ60B7W1
Colour White (Ral 9010)
Dimensions
Height mm 55 55 55 55 55
Width mm 700 700 700 700 700
Depth mm 700 700 700 700 700
Weight kg 2.7 2.7 2.7 2.7 2.7
Air Filter Resin net with mold resistance
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PC board fuse
Fan motor thermal protector
Standard
Accessories
Standard Accessories Installation and operation manual
Paper pattern for installation
Drain hose
Clamp metal
Washer fixing plate
Sealing Pads
Clamps
Screws
Washer for hanger bracket
Insulation for fitting
