Specifications SiENBE37-704

26 Specifications

1-1 TECHNICAL SPECIFICATIONS FXZQ20MV1B FXZQ25MV1B FXZQ32MV1B FXZQ40MV1B FXZQ50MV1B

Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,

equivalent refrigerant piping : 7.5m (horizontal)

Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,

equivalent refrigerant piping : 7.5m (horizontal)

Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.

1-2 ELECTRICAL SPECIFICATIONS FXZQ20MV1B FXZQ25MV1B FXZQ32MV1B FXZQ40MV1B FXZQ50MV1B

Power

Supply

Name V1

Phase 1 1 1 1 1

Frequency Hz 50 50 50 50 50

Voltage V 220-240

Current Minimum circuit amps

(MCA)

A 0.80 0.80 0.80 0.80 0.90

Maximum fuse amps

(MFA)

A 15.00 15.00 15.00 15.00 15.00

Full load amps (FLA) A 0.60 0.60 0.60 0.60 0.70

Voltage

range

Minimum V -10%

Maximum V +10%

Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or

above listed range limits.

Maximum allowable voltage range variation between phases is 2%.

MCA/MFA : MCA = 1.25 × FLA

MFA <= 4 × FLA

next lower standard fuse rating minimum 15A

select wire size based on the MCA

instead of a fuse, use a circuit breaker

For more details concerning conditional connections, see http://extranet. daikineurope.com, select "E-Data Books".

Finally, click on the document title of your choice.
