Specifications SiENBE37-704
34 Specifications
Slim Concealed Ceiling Unit (with Drain Pump)
1-1 TECHNICAL SPECIFICATIONS FXDQ20PVE FXDQ25PVE FXDQ32PVE FXDQ40NAVE FXDQ50NAVE FXDQ63NAVE
Nominal
Capacity
Cooling kW 2.20 2.80 3.60 4.50 5.60 7.10
Heating kW 2.50 3.20 4.00 5.00 6.30 8.00
Power input
(Nominal)
Cooling kW 0.086 0.086 0.089 0.160 0.165 0.181
Heating kW 0.067 0.067 0.070 0.147 0.152 0.168
Casing Material Galvanised steel plate
Dimensions Unit Height mm 200 200 200 200 200 200
Width mm 700 700 700 900 900 1,100
Depth mm 620 620 620 620 620 620
Weight Unit kg 23.0 23.0 23.0 27.0 28.0 31.0
Heat
Exchanger
Dimensions
Nr of Rows 2 2 3 3 3 3
Fin Pitch mm 1.50 1.50 1.50 1.50 1.50 1.50
Face Area m² 0.126 0.126 0.126 0.176 0.176 0.227
Nr of Stages 12 12 12 12 12 12
Fin Fin type Cross fin coil
Fan Type Sirocco fan
Quantity 1 1 1 1 1 1
Air Flow
Rate
Cooling High m³/min 8.0 8.0 8.0 10.50 12.50 16.50
Low m³/min 6.4 6.4 6.4 8.50 10.00 13.00
Fan External
static
pressure
High Pa 30 30 30 44 44 44
Standard Pa 10 10 10 15 15 15
Motor Output
(high)
W 62 62 62 62 130 130
Drive Direct drive
Refrigerant Name R-410A
Cooling Sound
Pressure
High dBA 33.0 33.0 33.0 34.0 35.0 36.0
Low dBA 29.0 29.0 29.0 30.0 31.0 32.0
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.4 6.4 6.4 6.4 6.4 9.5
Gas Type Flare connection
Diameter mm 12.7 12.7 12.7 12.7 12.7 15.9
Drain Diameter mm VP20 (I.D. 20/O.D. 26)
Air Filter Removable/washable/Mildew proof
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices Fuse
Fan motor thermal protector
Standard
Accessories
Standard Accessories Installation and operation manual
Drain hose
Sealing Pads
Clamps
Washer
Insulation for fitting
Clamp metal
Washer fixing plate
Screws for duct flanges
Air filter
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
External static pressure can be changed by the remote control.
The operation sound levels are conversion values in anechoic chamber. In practice,sound levels tend to be higher than
the specified values due to ambient noise or reflection. When the suction place is changed to bottom suction, sound level
will increase by approximately 5dBA.
