SiENBE37-704 Specifications

Specifications 37

1-1 TECHNICAL SPECIFICATIONS FXDQ20MV3B FXDQ25MV3B

Standard

Accessories

Standard Accessories Installation and operation manual

Fuse

Caution for servicing sticker

Suction air filter

Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,

equivalent refrigerant piping : 8m, level difference : 0m.

Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,

equivalent refrigerant piping : 8m, level difference : 0m.

Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.

1-2 ELECTRICAL SPECIFICATIONS FXDQ20MV3B FXDQ25MV3B

Power

Supply

Name V1

Phase 1 1

Frequency Hz 50 50

Voltage V 230 230

Current Minimum circuit amps

(MCA)

A 0.20 0.20

Maximum fuse amps

(MFA)

A 16.00 16.00

Full load amps (FLA) A 0.10 0.10

Voltage

range

Minimum V -10%

Maximum V +10%

Power Supply Intake Both indoor and outdoor unit

Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or

above listed range limits.

Maximum allowable voltage range variation between phases is 2%.

MCA/MFA : MCA = 1.25 × FLA

MFA < 4 × FLA

next lower standard fuse rating minimum 16A

select wire size based on the MCA

instead of a fuse, use a circuit breaker

For more details concerning conditional connections, see http://extranet.daikineurope.com, select "E-Data Books".

Finally, click on the document title of your choice.
