Specifications SiENBE37-704
38 Specifications
Concealed Ceiling Unit
1-1 TECHNICAL SPECIFICATIONS FXSQ20MV3B FXSQ25MV3B FXSQ32MV3B FXSQ40MV3B FXSQ50MV3B
Capacity
(Conditions
specified in 1)
Cooling kW 2.20 2.80 3.60 4.50 5.60
Heating kW 2.50 3.20 4.00 5.00 6.30
Power input
(Nominal)
Cooling kW 0.110 0.110 0.114 0.127 0.143
Heating kW 0.090 0.090 0.094 0.107 0.123
Casing Colour Non painted
Material Galvanised steel
Dimensions Packing Height mm 354 354 354 354 354
Width mm 742 742 742 892 892
Depth mm 936 936 936 936 936
Unit Height mm 300 300 300 300 300
Width mm 550 550 550 700 700
Depth mm 800 800 800 800 800
Weight Unit kg 30 30 30 30 31
Packed Unit kg 34 34 34 34 35
Required Ceiling Void mm 350 350 350 350 350
Heat
Exchanger
Dimensions
Length mm 300 300 300 450 450
Nr of Rows 3 3 3 3 3
Fin Pitch mm 1.75 1.75 1.75 1.75 1.75
Nr of Passes 3 3 3 4 4
Face Area m² 0.088 0.088 0.088 0.132 0.132
Nr of Stages 14 14 14 14 14
Empty Tubeplate
Hole
14
Tube type Hi-XSS (7)
Fin Fin type Symmetric waffle louvre
Treatment Hydrophilic
Fan Type Sirocco fan
Quantity 1 1 1 1 1
Air Flow
Rate
Cooling High m³/min 9.00 9.00 9.50 11.50 15.00
Low m³/min 6.50 6.50 7.00 9.00 11.00
Heating High m³/min 9.00 9.00 9.50 11.50 15.00
Low m³/min 6.50 6.50 7.00 9.00 11.00
Fan External
static
pressure
High Pa 125 125 104 116 136
Standard Pa 105 105 88 98 114
Low Pa 96 96 78 85 99
Motor Quantity 1 1 1 1 1
Model D18H3AA1V1 D18H3AA1V1 D18H3AA1V1 D18H2AC1V1 D18H2AB1V1
Steps step motor
Output
(high)
W 50 50 50 65 85
Drive Direct drive
Refrigerant Name R-410A
Sound Level Cooling Sound
power
(nominal)
dBA 50.0 50.0 51.0 56.0 58.0
Cooling Sound
Pressure
High dBA 32.0 32.0 33.0 33.0 35.0
Low dBA 28.0 28.0 28.0 29.0 31.0
Heating Sound
Pressure
High dBA 32.0 32.0 33.0 33.0 35.0
Low dBA 28.0 28.0 28.0 29.0 31.0
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.35 6.35 6.35 6.35 6.35
Gas Type Flare connection
Diameter mm 12.7 12.7 12.7 12.7 12.7
Drain Diameter mm 32 32 32 32 32
Heat Insulation Both liquid and gas pipes
