Specifications SiENBE37-704
40 Specifications
Concealed Ceiling Unit
1-1 TECHNICAL SPECIFICATIONS FXSQ63MV3B FXSQ80MV3B FXSQ100MV3B FXSQ125MV3B
Capacity
(Conditions
specified in
1)
Cooling kW 7.10 9.00 11.20 14.00
Heating kW 8.00 10.00 12.50 16.00
Power input
(Nominal)
Cooling kW 0.189 0.234 0.242 0.321
Heating kW 0.169 0.214 0.222 0.301
Casing Colour Non painted
Material Galvanised steel
Dimensions Packing Height mm 354 356 356 356
Width mm 1,192 1,596 1,596 1,596
Depth mm 936 938 938 938
Unit Height mm 300 300 300 300
Width mm 1,000 1,400 1,400 1,400
Depth mm 800 800 800 800
Weight Unit kg 41 51 51 52
Packed Unit kg 47 58 58 59
Required Ceiling Void mm 350 350 350 350
Heat
Exchanger
Dimensions
Length mm 750 1,150 1,150 1,150
Nr of Rows 3 3 3 3
Fin Pitch mm 1.75 1.75 1.75 1.75
Nr of Passes 7 10 10 10
Face Area m² 0.221 0.338 0.338 0.338
Nr of Stages 14 14 14 14
Tube type Hi-XSS (7)
Fin Fin type Symmetric waffle louvre
Treatment Hydrophilic
Fan Type Sirocco fan
Quantity 2 3 3 3
Air Flow
Rate
Cooling High m³/min 21.00 27.00 28.00 38.00
Low m³/min 15.50 20.00 20.50 28.00
Heating High m³/min 21.00 27.00 28.00 38.00
Low m³/min 15.50 20.00 20.50 28.00
Fan External
static
pressure
High Pa 123 141 141 109
Standard Pa 111 125 125 93
Low Pa 98
Motor Quantity 1 1 1 1
Model 2D18H2AB1V1 3D18H2AH1V1 3D18H2AH1V1 3D18H2AG1V1
Steps step motor
Output
(high)
W 125 135 135 225
Drive Direct drive
Refrigerant Name R-410A
Sound Level Cooling Sound
power
(nominal)
dBA 56.0 55.0 56.0 65.0
Cooling Sound
Pressure
High dBA 35.0 37.0 38.0 40.0
Low dBA 30.0 31.0 33.0 35.0
Heating Sound
Pressure
High dBA 35.0 37.0 38.0 40.0
Low dBA 30.0 31.0 33.0 35.0
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 9.5 9.5 9.5 9.5
Gas Type Flare connection
Diameter mm 15.9 15.9 15.9 15.9
Drain Diameter mm 32 32 32 32
Heat Insulation Both liquid and gas pipes
