SiENBE37-704 Specifications
Specifications 41
1-1 TECHNICAL SPECIFICATIONS FXSQ63MV3B FXSQ80MV3B FXSQ100MV3B FXSQ125MV3B
Decoration
Panel
Model BYBS71DJW1 BYBS125DJW1 BYBS125DJW1 BYBS125DJW1
Colour White (10Y9/0,5)
Dimensions
Height mm 55 55 55 55
Width mm 1,100 1,500 1,500 1,500
Depth mm 500 500 500 500
Weight kg 4.5 6.5 6.5 6.5
Drain-up Height mm 600 600 600 600
Air Filter Resin net with mold resistance
Air direction control Up and downwards
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PC board fuse
Drain pump fuse
Fan motor thermal fuse Fan motor thermal protector Fan motor thermal protector Fan motor thermal protector
Standard
Accessories
Standard Accessories Metal clamp for drain hose
Quantity 1 1 1 1
Standard Accessories Paper pattern for installation
Quantity 1 1 1 1
Standard Accessories Drain hose
Quantity 1 1 1 1
Standard Accessories Insulation for fitting
Quantity 2 2 2 2
Standard Accessories Washer for hanger bracket
Quantity 8 8 8 8
Standard Accessories Screws for duct flanges
Quantity 12 16 16 16
Standard Accessories Screws for fixing the paper pattern for installation
Quantity 6 6 6 6
Standard Accessories Fuse
Installation and operation manual
Quantity 1 1 1 1
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 8m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB,19°CWB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 8m, level difference : 0m.
The external static pressure is changeable : change the connectors inside the electrical box, this pressure means :
High static pressure - standard - low static pressure
The external static pressure is changeable : change the connectors inside the electrical box, this pressure means :
High static pressure - standard
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
The sound pressure values are mentioned for a unit installed with rear suction
