Specifications SiENBE37-704

42 Specifications

1-2 ELECTRICAL SPECIFICATIONS FXSQ20MV3B FXSQ25MV3B FXSQ32MV3B FXSQ40MV3B FXSQ50MV3B

Power

Supply

Name V3

Phase 1 1 1 1 1

Frequency Hz 50 50 50 50 50

Voltage V 230 230 230 230 230

Current Minimum circuit amps

(MCA)

A 0.50 0.50 0.50 0.60 0.90

Maximum fuse amps

(MFA)

A 16.00 16.00 16.00 16.00 16.00

Full load amps (FLA) A 0.40 0.40 0.40 0.50 0.70

Voltage

range

Minimum V -10%

Maximum V +10%

Notes Voltage range: units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or

above listed range limits.

Maximum allowable voltage range variation between phases is 2%

MCA/MFA : MCA = 1.25 × FLA

MFA < 4 × FLA

next lower standard fuse rating minimum 16A

select wire size based on the MCA

instead of a fuse, use a circuit breaker

For more details concerning conditional connections, see http://extranet.daikineurope.com, select"E-Data Books".

Finally, click on the document title of your choice.

1-2 ELECTRICAL SPECIFICATIONS FXSQ63MV3B FXSQ80MV3B FXSQ100MV3B FXSQ125MV3B

Power

Supply

Name V3

Phase 1 1 1 1

Frequency Hz 50 50 50 50

Voltage V 230 230 230 230
